1300mm×1050mm Paper Box Gluing Machine 18KW One Year Warranty
1300mm×1050mm Paper Box Gluing Machine 18KW One Year Warranty
1300mm×1050mm Paper Box Gluing Machine 18KW One Year Warranty
1300mm×1050mm Paper Box Gluing Machine 18KW One Year Warranty
1300mm×1050mm Paper Box Gluing Machine 18KW One Year Warranty
1300mm×1050mm Paper Box Gluing Machine 18KW One Year Warranty
Specifications
Brand Name :
Deshisen
Model Number :
ZH1000-4A
Certification :
CE
Place of Origin :
SHENZHEN CHINA
MOQ :
1 SET
Price :
CNY 147,000.00/SET
Payment Terms :
T/T
Supply Ability :
20 SET 25Day
Delivery Time :
5-8 work day
Packaging Details :
Wooden packaging
color :
The polar grey,orange
Power :
18KW (380V AC 3φ 50Hz)
Weight :
1600kg
Dimension(l*w*h) :
6600*2100*1600
Type :
Gluing Machine
after sales service :
good service
After-sales Service :
Video technical support,Online support
Packaging Material :
Wood
Description

Zipper Shipping Boxes Machine / carton box packaging machine / Warranty one year / 6600*2100*1600

Description of machine

Full automatic stick double-sided adhesive machine is designed and researched by Deshisen CO., Ltd for single sheet water-based printing of corrugated container, Offset printing color-mounted corrugated cardboard boxes, cardboard color boxes, etc., affixed with double-sided tape and easy-to-tear tape simultaneously.

Any type of coding system can be set up on the platform for variable information printing, and a labeling head can be optionally installed. Local labeling function can be installed as well.

This series adopts a more optimized modular design, users can have more personalized choices, and achieve a multi-purpose design concept.

This equipment is widely used in pharmaceutical packaging, food packaging, logistics packaging, gift box packaging and other fields.

Instruction:
Semi-automatic press model folder&gluer speicail to meet middle and small orders, small CBM, easy operation, widely use range, it is suit for normal box, special shape color box. Add automatic gluing device also can produce hook bottom box and earth cover carton, save glue, labour, maxmium run speed 60m/min, the effective is 3-4times than normal mahcine; gluing firmly, trimly and don't over glue,with double head sander remove UV or film. Improve adhensive.

Specification:
Model ZH1000-4A is the hot sale of the company. The users praise its stability, versatility and flexibility.It can paste many kinds of boxes. For small ones,it can make 40,000 to 50,000 pcs per hour. It' sideal equipment in printing industry.

Supplement:

This machine can be added with a shell, which is not only beautiful, but also has a protective effect.As shown below .

color The polar grey,orange Working width 1310MM
material ≥300g/m²cartons Air compressor min. 6 bar
Minimum paper size 250mm×250mm total power 18 KW (380V AC 3φ 50Hz)
Maximum paper size 1300mm×1050mm weight 1600KG
The highest speed 60m/min-100m/min Machine dimensions 6600*2100*1600
