Explosion Proof Pulse Jet Dust Collectors with PTFE Pleated Bag Foundries Support
Explosion Proof Pulse Jet Dust Collectors with PTFE Pleated Bag Foundries Support
Explosion Proof Pulse Jet Dust Collectors with PTFE Pleated Bag Foundries Support
Explosion Proof Pulse Jet Dust Collectors with PTFE Pleated Bag Foundries Support
Specifications
Brand Name :
AUZOER
Model Number :
ADC-11-20
Place of Origin :
CHINA
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
300 pcs per year
Delivery Time :
30-60 days
Packaging Details :
Wooden cases package
Certification :
ISO
Name :
bag type dust collector
Material :
Carbon Steel
Efficiency :
99.9%
Type :
Fabric Dust Collector
Filtering area :
17-5962 ㎡
Air volume :
1530-536580 m3/h
Power :
0.75-5.5kw,Customize
Application :
Dust Collect,fabric,blast furnace blower,cement,Steel Mills and/or Foundries
Description

Explosion Proof Pulse Jet Dust Collectors with PTFE Pleated Bag Foundries Support

ADC Baghouse Dust Collector

Dust-laden gas or air enters the baghouse through hoppers and is directed into the baghouse compartment. The gas is drawn through the bags, either on the inside or the outside depending on cleaning method, and a layer of dust accumulates on the filter media surface until air can no longer move through it.
Baghouses are industrial dust collectors that use anywhere from 6 to 900 felt bags to filter dusty air produced by various manufacturing and processing applications. In most baghouses, a large fan pulls dusty air into the collector where the dust collects on the exterior of the felt bags and cleaned air then exits the collector. We offer a complete line of dependable, rugged baghouse dust collectors to keep your operation running smoothly.

Technical Data

Model Modular Qty Modular Dimension Valve Quantity Filter Quantity Filter Length(mm) Filter Area(㎡)
Length Height L(mm) W(mm) H(mm) Circular Bag Pleated Bag Long Cartridge
ADC-11-10 1 1 1524 1524 4800 6 36 1000 17 31 83
ADC-11-20 1 1 1524 1524 5808 6 36 2000 34 61 166
ADC-11-30 1 1 1524 1524 6816 6 36 3000 51 92 248
ADC-21-20 2 1 3037 1524 5808 12 72 2000 68 122 331
ADC-21-30 2 1 3037 1524 6816 12 72 3000 102 183 497
ADC-31-30 3 1 4550 1524 6816 18 108 3000 153 275 745
ADC-41-30 4 1 6063 1524 6816 24 144 3000 203 366 994
ADC-41-40 4 1 6063 1524 7824 24 144 4000 271 488 1325
ADC-51-30 5 1 7576 1524 6816 30 180 3000 254 458 1242
ADC-51-40 5 1 7576 1524 7824 30 180 4000 339 610 1656
ADC-32-50 3 2 4550 3037 8832 36 216 5000 509 916 2484
ADC-32-60 3 2 4550 3037 9840 36 216 6000 610 1099 2981
ADC-42-50 4 2 6063 3037 8832 48 288 5000 678 1221 3312
ADC-42-60 4 2 6063 3037 9840 48 288 6000 814 1465 3974
ADC-52-50 5 2 7576 3037 8832 60 360 5000 848 1526 4140
ADC-52-60 5 2 7576 3037 9840 60 360 6000 1017 1831 4968
ADC-62-50 6 2 9089 3037 8832 72 432 5000 1017 1831 4968
ADC-62-60 6 2 9089 3037 9840 72 432 6000 1221 2197 5962

The modular parts are designed for freely assembly with accurate processing,strict quality control which could realize mass production and shortened lead time.

Explosion Proof Pulse Jet Dust Collectors with PTFE Pleated Bag Foundries Support

Through the air flow simulation optimization, shell strength optimization to ensure the efficient and safe operation of the dust collector.

Explosion Proof Pulse Jet Dust Collectors with PTFE Pleated Bag Foundries Support

Explosion Proof Pulse Jet Dust Collectors with PTFE Pleated Bag Foundries Support

Explosion Proof Pulse Jet Dust Collectors with PTFE Pleated Bag Foundries Support
