Low Pressure Industrial Dust Removal System / Industrial Baghouse Dust Collectors
Low Pressure Industrial Dust Removal System / Industrial Baghouse Dust Collectors
Specifications
Brand Name :
AUZOER
Model Number :
ADC-21-20
Certification :
ISO
Place of Origin :
CHINA
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
300 pcs per year
Delivery Time :
3-8 weeks
Packaging Details :
Wooden Cases or Wooden Pallets
Condition :
New
Weight :
1220kgs~3200kgs
Name :
bag type dust collector
Material :
Carbon Steel
Efficiency :
99%
Filtering area :
1260~8100 m³,96 - 1728 M2
Air volume :
5900-314000 m3/h,5000 - 120200m3 / h,8250-198000m3/h
Power :
0.75-5.5kw,Customize
Application :
Grinding, Laser Cutting, Machining, Mixing, Polishing, Welding, Wood Working, Bulk Powder, Composites Machining, Powder Coating.
Description

Low Pressure Industrial Dust Removal System / Industrial Baghouse Dust Collectors

Dust Collector – Baghouse

Dust Collector/Baghouse Advantages

  • Automated self-cleaning of filter bags
  • Designed to handle streams with granular particulates
  • Hoppers collect granules which can be valuable in some applications
  • Continuous operation possible
  • High filter rates
  • No internal moving part
  • High ROI due to collected product
  • Low maintenance requirements
  • Fast top removal of bags – working at the clean air side
  • Dependable solid-state timer controls
  • Weather proof – all welded construction

ADC Technical Data

Model Modular Qty Modular Dimension Valve Quantity Filter Quantity Filter Length(mm) Filter Area(㎡)
Length Height L(mm) W(mm) H(mm) Circular Bag Pleated Bag Long Cartridge
ADC-11-10 1 1 1524 1524 4800 6 36 1000 17 31 83
ADC-11-20 1 1 1524 1524 5808 6 36 2000 34 61 166
ADC-11-30 1 1 1524 1524 6816 6 36 3000 51 92 248
ADC-21-20 2 1 3037 1524 5808 12 72 2000 68 122 331
ADC-21-30 2 1 3037 1524 6816 12 72 3000 102 183 497
ADC-31-30 3 1 4550 1524 6816 18 108 3000 153 275 745
ADC-41-30 4 1 6063 1524 6816 24 144 3000 203 366 994
ADC-41-40 4 1 6063 1524 7824 24 144 4000 271 488 1325
ADC-51-30 5 1 7576 1524 6816 30 180 3000 254 458 1242
ADC-51-40 5 1 7576 1524 7824 30 180 4000 339 610 1656
ADC-32-50 3 2 4550 3037 8832 36 216 5000 509 916 2484
ADC-32-60 3 2 4550 3037 9840 36 216 6000 610 1099 2981
ADC-42-50 4 2 6063 3037 8832 48 288 5000 678 1221 3312
ADC-42-60 4 2 6063 3037 9840 48 288 6000 814 1465 3974
ADC-52-50 5 2 7576 3037 8832 60 360 5000 848 1526 4140
ADC-52-60 5 2 7576 3037 9840 60 360 6000 1017 1831 4968
ADC-62-50 6 2 9089 3037 8832 72 432 5000 1017 1831 4968
ADC-62-60 6 2 9089 3037 9840 72 432 6000 1221 2197 5962

Low Pressure Industrial Dust Removal System / Industrial Baghouse Dust Collectors
