180KN 30km/h 250T Aircraft Tow Tractor For Airplane Pushback
180KN 30km/h 250T Aircraft Tow Tractor For Airplane Pushback
180KN 30km/h 250T Aircraft Tow Tractor For Airplane Pushback
180KN 30km/h 250T Aircraft Tow Tractor For Airplane Pushback
180KN 30km/h 250T Aircraft Tow Tractor For Airplane Pushback
180KN 30km/h 250T Aircraft Tow Tractor For Airplane Pushback
180KN 30km/h 250T Aircraft Tow Tractor For Airplane Pushback
180KN 30km/h 250T Aircraft Tow Tractor For Airplane Pushback
Specifications
Brand Name :
TECHKING
Model Number :
TK-QY180
Certification :
CCC
Place of Origin :
CHINA
MOQ :
1
Price :
By negociation
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
10 Units/Month
Delivery Time :
120 days
Packaging Details :
Nude Pack, Loaded in Flat Rack Container or Shipped by R&R
Name :
TECKING Aircraft Towing Tractor
Dimensions :
7270*2600*1650mm
Towing Capacity :
250T
Gross Vehicle Weight :
25000 KG
Maximum Speed :
30km/h
Min. Turning Diameter :
11800 mm
Front Hitch Ground Clearance :
330 mm
Front Hook Ground Clearance :
300 mm
Description

Aircraft Tow Tractor For Airplane Pushback For A321 With 180KN

Aircraft Tow Tractor The HF6150 series aircraft, using the newest European technology, is designed to push and pull all know narrow body and ro certain extend medium body aircrafts.

The max draw bar pull for this series is up to 180KN The aircraft includes B717; B727; B737; B757; B767-200; A318; A319; A320; A321; A300; A310 or any aircraft below 300,000 kg. It ergonomic designed provides agility, visibility, durable and reliable tractors. One of the unit designs is that it has three antenna type safety swithces, similar to other raised cab heavy tractor.

Any one of these touches an onstacle, it will stop the vehicle completely. This will prevent any accident happened.

Description:

The TK-QY200 aircraft tow tractor offers reliable aircraft push and pull service in full compliance with CAAC andinternational standards, such as, IATA AHM 905, IATA AHM 910, IATA AHM 913, IATA AHM915, IATAAHM 916, IATA AHM 955,MH/T6017 etc.

180KN 30km/h 250T Aircraft Tow Tractor For Airplane Pushback

Specifications for Aircraft Tow Tractor:

Dimensions Performance
Overall Dimensions 7270*2600*1650mm Tow Bar Pull 180 KN
Wheel Base 2750 mm Towing Capacity 250000 KG
Front/Rear AxleTread 2230mm Gross Vehicle Weight 25000 KG
Ground Clearance 200 mm Maximum Speed 31 km/hr
Min. Turning Diameter 11800 mm
Front Hitch Ground Clearance 265/395 mm
Rear Hitch Ground Clearance 370/470 mm

180KN 30km/h 250T Aircraft Tow Tractor For Airplane Pushback

Applicable Aircraft:

A300-600,A310-200, A310-300, A321, A318,A319, A320,A330-200, A330-300, B717, B737, B757,B767-300, B767-400, B787-3, B787-8, B787-9

180KN 30km/h 250T Aircraft Tow Tractor For Airplane Pushback
