industrial grade SAW Touch Monitor Open Frame Touch Screen Monitor Anti Glare
industrial grade SAW Touch Monitor Open Frame Touch Screen Monitor Anti Glare
industrial grade SAW Touch Monitor Open Frame Touch Screen Monitor Anti Glare
industrial grade SAW Touch Monitor Open Frame Touch Screen Monitor Anti Glare
industrial grade SAW Touch Monitor Open Frame Touch Screen Monitor Anti Glare
industrial grade SAW Touch Monitor Open Frame Touch Screen Monitor Anti Glare
Specifications
Brand Name :
rCloud
Model Number :
RCS-TM120S
Certification :
CE.FC,Rohs
Place of Origin :
China
MOQ :
1PCS
Price :
Negotiation
Payment Terms :
T/T, Western Union,Paypal, L/C
Supply Ability :
1000pcs per month
Delivery Time :
5-8 work days
Packaging Details :
Cartoon
Screen Size :
12 inch
Type :
IntelliTouch
Interface Type :
Serial, USB
Resolution :
800 x 600
Contrast :
500:1
Net weight :
4.3KG
Description

industrial grade SAW Touch Monitor Open Frame Touch Screen Monitor Anti Glare

Specification:

Series Metal-cased open frame
Monitor Dimensions Width: 298mm Height: 237mm Depth47mm
Weight(N.W/G.W) 4.3Kg / 5.8Kg (Approx.)
LCD Type 12.1"Active matrix TFT-LCD
Video Input VGA&DVI
Touch interface USB
Recommend Resolution 800×600@60Hz
Active Area(mm) 246.0(H)×184.5(V)
Dot Pitch(mm) 0.3075×0.3075
Nominal Input Voltage VDD +3.3V(Typ)
Viewing angle (v/h) 80°/60°
Contrast 500:1
Luminance(cd/m2) 380
Response Time(Rising/Falling) 30ms/30ms
Support Color 16.2M/262K colors
Backlight MTBF(hr) 20000(min)
Output 12V/DC/4A
Input 100-240 VAC, 50-60 Hz
MTBF 50000 hr at 25°C
Operating Temp. 0~50°C
Storage Temp. -20~60°C
Operating RH: 20%~80%
Storage RH: 10%~90%
OSD controls Allow on-screen adjustments of Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset
Power Supply Type: External brick
Input (line) voltage: 100-240 VAC, 50-60 Hz
Output voltage/current: 12 volts at 4 amps max
Mount Interface

1)VESA 75mm and 100mm

2)Mount bracket, horizontal or vertical
Regular Warranty 3 years for SAW touch screen; 1 year for LCD
Agency Approval FCC,CE

industrial grade SAW Touch Monitor Open Frame Touch Screen Monitor Anti Glare
