Wall Mounted SAW Touch Screen Monitor Usb Rs232 10 Point Multi Touch IP 65
Wall Mounted SAW Touch Screen Monitor Usb Rs232 10 Point Multi Touch IP 65
Wall Mounted SAW Touch Screen Monitor Usb Rs232 10 Point Multi Touch IP 65
Wall Mounted SAW Touch Screen Monitor Usb Rs232 10 Point Multi Touch IP 65
Wall Mounted SAW Touch Screen Monitor Usb Rs232 10 Point Multi Touch IP 65
Wall Mounted SAW Touch Screen Monitor Usb Rs232 10 Point Multi Touch IP 65
Specifications
Brand Name :
rCloud
Model Number :
RCS-TM170S
Certification :
CE.FC,Rohs
Place of Origin :
China
MOQ :
1PCS
Price :
Negotiation
Payment Terms :
T/T, Western Union,Paypal, L/C
Supply Ability :
1000pcs per month
Delivery Time :
5-8 work days
Packaging Details :
Cartoon
Screen Size :
17 inch
Type :
IntelliTouch
Interface Type :
D-Sub, DVI, Serial, USB
Resolution :
1280 x 1024
IP rate :
IP 65
Weight :
6KG
Description

Wall Mounted SAW Touch Screen Monitor Usb Rs232 10 Point Multi Touch IP 65

17 inch Open frame Waterproof SAW touch screen monitor
Size:15-inch,17-inch,19-inch
touch monitor - Waterproof / Dustproof / Vanalproof / Anti-glare / Multi-touch / Customized availavle
SAW touch monitor: 8"-32"
Infrared touch monitor: 10.4"-65"
Capacitive touch monitor: 10.1-55"

General

Series Water-proof and Compact
Monitor Dimensions Width: 415mm Height: 343mm Depth: 54.2mm
Weight(N.W/G.W) 6Kg / 8Kg (Approx.)
LCD Type 19"SXGA Color TFT-LCD (Panel Model :G190EG01 V0)
Video Input VGA + DVI
Recommend Resolution 1280×1024@75Hz
OSD controls Allow on-screen adjustments of Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset
Power Supply Type: External brick
Input (line) voltage: 100-240 VAC, 50-60 Hz
Output voltage/current: 12 volts at 4 amps max
Mount Interface

1)VESA 75mm and 100mm
2)Mount bracket, horizontal or vertical
Regular Warranty 5 years for SAW Sensor; 3 years for controller; 1 year for LCD
Agency Approval FCC,CE,RoHS


2. LCD specs

Active Area(mm) 376.320(H)×301.060(V)
Resolution 1280×1024@75Hz
Dot Pitch(mm) 0.294×0.294
Nominal Input Voltage VDD +5.0V(Typ)
Viewing angle (v/h) 80°/85°
Contrast 1000:1
Luminance(cd/m2) 250
Response Time(Rising/Falling) 3.5s/1.5s
Support Color 16.7M colors
Backlight MTBF(hr) 50000
NOTE:The LCD Specification will change follow the relevant LCD panel brand and model



Touch screen

Type Surface Acoustic Wave(SAW)
Resolution 4096*4096
Light Transmission 92%
Touch Life Cycle 50 millions
Touch Response time 16ms
Touch System Interface RS-232 and USB interface
Power consumption +5V@80mA

Wall Mounted SAW Touch Screen Monitor Usb Rs232 10 Point Multi Touch IP 65
