5 Color TFT LCD Module Display ILI6122 Driver IC Capacitive Multi Touch Panel
5 Color TFT LCD Module Display ILI6122 Driver IC Capacitive Multi Touch Panel
5 Color TFT LCD Module Display ILI6122 Driver IC Capacitive Multi Touch Panel
5 Color TFT LCD Module Display ILI6122 Driver IC Capacitive Multi Touch Panel
5 Color TFT LCD Module Display ILI6122 Driver IC Capacitive Multi Touch Panel
5 Color TFT LCD Module Display ILI6122 Driver IC Capacitive Multi Touch Panel
Specifications
Brand Name :
rCloud
Certification :
CE
Place of Origin :
China
MOQ :
1PCS
Price :
Negotiation
Payment Terms :
T/T, Western Union,Paypal, L/C
Supply Ability :
1000pcs per month
Delivery Time :
5-8 work days
Packaging Details :
Cartoon
name :
LCD display module
module structure :
LCD + CTP + PCB
power supply :
5v
backlight type :
White LED
module size :
120.8*75.95*6.73mm
port :
Shenzhen/Hong Kong
Description

5" color tft lcd module display with ILI6122 driver IC capacitive multi-touch panel screen

Introduction

It is 800x480 dots 5" color tft lcd module display with ILI6122 driver IC,optional 5 points capacitive multi-touch panel with controller GSL1680 and optional 4-wire resistive touch panel screen,superior display quality,super wide view angle and easily controlled by MCU such as 8051, PIC, AVR, ARDUINO, ARM and Raspberry PI.

This module can be used in any embedded systems,car,mp4,gps,industrial device,security and hand-held equipment which requires display in high quality and colorful image.It supports rgb interface. FPC with zif connector is easily to assemble or remove.

Feature

Suitable for working in harsh environment.

Effectively save energy and make the product lighter and thinner.

Ultra fast response time.

Suitable for outdoor flash demand.

Widely used.

Specification

Item of general information

Contents

Unit

LCD Display Size (Diagonal)

5.0

inch

Module Structure

LCD + CTP + PCB

-

LCD Display Type

IPS

-

LCD Display Mode

Normally Black

-

Recommended Viewing Direction

ALL VIEW

-

Module size (W×H×T)

120.80×75.95×6.73

mm

Active area (W×H)

108.00×64.8

mm

Number of pixels (Resolution)

800RGB×480

pixel

Pixel pitch (W×H)

0.135×0.135

mm

Color Pixel Arrangement

RGB Stripe

-

Module Interface Type

LCD

LVDS/HDMI/RGB

-

CTP

USB

-

System Support

Win10/Win11(HDMI)

-

Android/Linux (need to be configured first)

-

Power Supply

Micro USB (5.0V)

-

Module Power consumption

500(Max)

mA

Color Numbers

16.7M

-

Backlight Type

White LED

-

Application

bus, subway

airport

shopping mall

security monitoring

command and dispatching center

exhibition system of exhibition center

multimedia education
