OEM EN124 750x400mm Ductile Iron Channel Grating
OEM EN124 750x400mm Ductile Iron Channel Grating
OEM EN124 750x400mm Ductile Iron Channel Grating
OEM EN124 750x400mm Ductile Iron Channel Grating
OEM EN124 750x400mm Ductile Iron Channel Grating
OEM EN124 750x400mm Ductile Iron Channel Grating
OEM EN124 750x400mm Ductile Iron Channel Grating
OEM EN124 750x400mm Ductile Iron Channel Grating
OEM EN124 750x400mm Ductile Iron Channel Grating
OEM EN124 750x400mm Ductile Iron Channel Grating
Specifications
Brand Name :
OEM
Model Number :
750*400mm
Certification :
ISO9001
Place of Origin :
China
MOQ :
500 Pieces
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
10000/month
Delivery Time :
4 weeks
Packaging Details :
wooden crates
Material :
ductile iron
Process :
Sand casting
Dimensions :
750*400mm
Standard :
EN124 Standard,EN1433,ISO9001
Color :
black,Pitch black or as per customer's requirement.
Service :
OEM
Surface Treatment :
Varnish
Load-bearing :
C250
Apperance :
Process with supplied drawings
Connection Type :
Threaded
Description

750*400mm Processing With Supplied Drawing Ductile Iron Channel Grating

Characteristic Customized Product, Produce According to the Drawings Provided by Customers
Specification Type Class A15,B125,C250,D400,E600,F900
Main Market Ameica and Europe
Brand ZHF Registered in America and Europe


CLASS A15 - Areas to be used only by pedestrians and cyclists.

CLASS B125 - Pavements, pedestrianised areas and similar surfaces,parking areas and multistorey car parks.

CLASS C250 - For covering devices installed on roadsides and in gutters at the side of streets.

CLASS D400 - Road surfaces (including pedestrianised streets), hard shoulders and parking areas for vehicles of all kinds.
CLASS E600 - Areas used by heavy vehicles, such as surfaces in airport and dock facilities.

CLASS F900 - Areas sudject to particularly heavy loading, for example surfaces in airports.

Usage of Ductile Iron Channel Grating: Floor Drain

Product Type of Ductile Iron Channel Grating: Class A15,B125,C250,D400,E600,F900

Features of Ductile Iron Channel Grating: Long life, high machining precision

Testing capacity
We have a full set of quality control system to guarantee quality, and we can do relative test such as below:
Chemical component analysis
Mechanical property
Metallographic analysis
Ultrasonic testing
Magnetic testing
Radiographic testing
Penetrant testing
Leak testing
OEM EN124 750x400mm Ductile Iron Channel GratingOEM EN124 750x400mm Ductile Iron Channel GratingOEM EN124 750x400mm Ductile Iron Channel GratingOEM EN124 750x400mm Ductile Iron Channel GratingOEM EN124 750x400mm Ductile Iron Channel Grating

Hebei Zhonghe Foundry Co., LTD.,“ZHF” for short, an ISO9001 certified export-oriented enterprise, was established in 2003, specializing in gray iron and ductile iron castings, such as cast iron drainage parts, ductile iron flanges, cast iron pump & valve parts, farm machinery castings, channels & manhole covers, etc., widely used in commercial and civil buildings, municipal water supply and drainage, and other industrial fields. We are the world's largest supplier of cast-iron drainage products of North America market and have been exporting steadily for more than 15 years.

We own 20,000 square meters modern casting workshop, including one full-automatic casting production line imported from Japanese, one horizontal molding line, and one automatic molding line, which can meet all kinds of small pieces and large pieces. We also own three machining workshops, total 10000 square meters, equipped with various CNC lathes, milling machines, drilling machines, which can nearly meet all kinds of machining. We have one automatic spraying paint workshop of 5000 square meters, which can meet 100 tons output per day. An annual production capacity is more than 50,000 tons of all kinds of iron castings.

We have invested heavily money in various environmental protection facilities, and passed the acceptance of environmental protection administration. We have obtained the qualification of class A factory, which means the production will not be affected by the pollution weather warning, and then will not influence delivery time.

We are dedicated to continous inprovement. As an OEM customer,we invite you to experience the streamlined process,higher quality,better compliance product that's faster to market.
