Coaxial Cable RG6 CATV Tri Shield High Frequency Low Loss Cable
Coaxial Cable RG6 CATV Tri Shield High Frequency Low Loss Cable
Coaxial Cable RG6 CATV Tri Shield High Frequency Low Loss Cable
Coaxial Cable RG6 CATV Tri Shield High Frequency Low Loss Cable
Coaxial Cable RG6 CATV Tri Shield High Frequency Low Loss Cable
Coaxial Cable RG6 CATV Tri Shield High Frequency Low Loss Cable
Specifications
Brand Name :
Libo
Model Number :
RG6
Certification :
ROHS REACH California Proposition 65 ISO 9000 ISO140001
Place of Origin :
China
MOQ :
1 meter
Price :
USD
Payment Terms :
D/P, L/C, T/T, D/P
Supply Ability :
20000000 meters
Delivery Time :
1-2 weeks
Packaging Details :
Roll or reel or different packing is available upon request
Inner conductor :
High quality copper clad steel
Shielding :
Tri Shield
Jacket :
ROHS PVC or PE
Packing :
305 meters per reel or as per customer's requirement
Color :
Black or White or Blue or Yellow
Description
RG6 T60 CCST Technical Specification
OBJECT Coaxial Cable Brand 　
GRADE RG6 Tri
TEST ITEMS UNIT LIMITS Material
Conductor mm 1.02±0.02 Copper Cover Steel
Dielectric Thickness 1.775±0.065 Foam polyethylene
Diameter 4.57±0.13 　
AL Tape 0.05 Aluminum/Poly tapeBonded
Outer conductor Braiding Coverage 0.12±0.005 x80 wire H=32mmCoverage 57% 0.12mmAluminum
AL TAPE 0.05 Aluminum/Poly tape /Aluminum Nonbonded
Jacket wall thickness 0.76±0.15 (White or Black), ROHS and CPR E flame retardant PVC
Diameter Over Jacket 7.0±0.2 　
Attenuation(1000MHz, 20℃) dB/100m NetworkAnalyzer 5MHZ 2.70dB 　
55MHz 5.25 dB↓ 　
211 MHz 10.0 dB↓ 　
270 MHz 11.0 dB↓ 　
300 MHz 11.6 dB↓ 　
330 MHz 12.3 dB↓ 　
400 MHz 13.6 dB↓ 　
450 MHz 14.4 dB↓ 　
550 MHz 16.2 dB↓ 　
750 MHz 19.0 dB↓ 　
870 MHz 20.6 dB↓ 　
1000 MHz 21.49 dB↓ 　
Sparker test AVC 　 4000 　
Inner Voltage V 　 3000 Conductor to shield
Impedance Ω 　 75+3 　
Velocity propagation % 　 82 　
V.S.W.R(Return loss) 　 　 1.2↓(20 dB↑) 100% swept test
Insulation Resistance MΩ 　 1000↑(20℃) 　
Capacitance pF/m 　 53 　
Conductor & Dielectric To stick kgf 100mm/min ≥4.5kgf test sample length 5cm
