500MHZ Halogen Free Cable 9.50mm Dielectric For Perimeter Detection
500MHZ Halogen Free Cable 9.50mm Dielectric For Perimeter Detection
500MHZ Halogen Free Cable 9.50mm Dielectric For Perimeter Detection
500MHZ Halogen Free Cable 9.50mm Dielectric For Perimeter Detection
500MHZ Halogen Free Cable 9.50mm Dielectric For Perimeter Detection
500MHZ Halogen Free Cable 9.50mm Dielectric For Perimeter Detection
Specifications
Brand Name :
Libo
Model Number :
MSHA leaky feeder cable
Certification :
CE, ISO9000, ISO14001,RoSH, MSHA
Place of Origin :
China
MOQ :
0.1KM
Price :
Call or e-mail to get the latest price
Payment Terms :
T/T, L/C,DP
Supply Ability :
1000 KM per month
Delivery Time :
5 days
Packaging Details :
350m/500m/1000m or according to client’s request
Description

Low Smoke Halogen Free Leaky Feeder Cable SLYWV 75 - 10 Yellow Jacket

Quick Details

  • High quality oxygen free copper 99.99%
  • Virgin grade PE insulation
  • Flame retardant jacket
  • Low smoke free halogen jacket is availiable
  • MSHA certificate

Product Description:

The leaky feeder cable has a radiation pattern of 360 degrees around the cable and can be strapped directly to a centenary cable, water or air pipe. The standard length is 350m or 500m with a yellow outer jacket.

As an option, the cable can be manufactured according to order with a blue color outer jacket and low smoke halogen free jacket is also available.

MSHA certified leaky feeder cable, Meet IEC1196 and EN50117.

Applications:

  • Mines underground communication system
  • metro stations
  • tunnels
  • ships
  • In-building wireless systems.
  • perimeter detection

Specification:

Inner conductor

2.31mm bare copper

Dielectric

9.50mm

Outer conductor

16x0.6 bare copper wire

Outer jacket

15.0mm+/-0.2mm

Frequency

5 to 500MHZ

impedance

75 ohms

Attenuation @160 MHZ

4.2dB/100m

DC resistance inner conductor

＜4.5 ohm/km

DC resistance outer conductor

＜4.1 ohm/km

capacitance

54 pF/m

Insulation resistance

＞10.4m ohm/km

MIN. bend radius

150mm

Operating temperature

-40 to +70 centigrade

Competitive Advantage:

  • Libo cable was established in 1994, it covers over 340,000 square meters on our operating area.
  • Libo cable has a stable workforce and engineering team, our production and testing procedures are all strictly follow requirement of ISO9000, and ISO14000.
  • Libo cable is equipped with a Provincial-level Research and Development Center; we offer OEM and ODM services.
  • Over 10 years of experience on leaky feeder cable, big market share in oversea leaky feeder cable industry.500MHZ Halogen Free Cable 9.50mm Dielectric For Perimeter Detection
