High quality steel scrap CCM machine for foundary and steel plant/ CCM / continuous casting machine
High quality steel scrap CCM machine for foundary and steel plant/ CCM / continuous casting machine
Specifications
Brand Name :
Haijun
Model Number :
customization
Certification :
ISO 9001
Place of Origin :
Jiangsu, China (Mainland)
MOQ :
1 Set
Price :
Negotiable
Supply Ability :
90 days
Delivery Time :
30work days
Packaging Details :
Export safety package
Payment Terms :
T/T , L/C
Condition :
New
Voltage :
380V
Dimension :
(L*W*H): variable
After-sales Service Provided :
Overseas service center available
Steel Type :
Carbon Steel, Alloy Steel, Stainless Steel
Arc radius(m) :
R4,R5.25,R6,R8,R12
CCM total length(m) :
~37.5 m
Oscillation device :
non-disturb complex fully plate spri
Power(W) :
variable
Weight :
variable
Warranty :
12MONTHS
Product name :
continuous casting machine
Machine model :
fully arc type CCM
CCM strand quantity: :
1-20 strand
Cut-to-length :
6 /12 m
Secondary coolin :
Water Spray Cooling
Description
High quality steel scrap CCM machine for foundary and steel plant/ CCM / continuous casting machineName Continuous Casting Machine
Steel Type Carbon Steel, Alloy Steel, Stainless Steel
Machine model fully arc type CCM
Arc radius(m) R3,R4,R5.25,R6,R8
CCM metallurgical length(m) ~24
CCM strand quantity 1-20 strand
Strand spacing(mm) -
CCM total length(m) ~37.5 m
Billet out elevation +0.20m
Billet cross section(mm) 60*60,80*80,100*100,130*130,200mm×200mm
Cut-to-length 6 /12 m
Mould

Tube type,copper tube length is 900m,reserve built-

in electromagnetic stirring and level control

casting type:protecting type casting
Oscillation device non-disturb complex fully plate spring oscillation
Secondary cooling Water Spray Cooling
Withdrawal straightening machine 5 rolls split-type stand;continuous withdrawal& straightening
Roller surface linear speed of withdrawal straightening machine ~4.5 m/min
Dummy bar type rigid dummy bar
Dummy bar storage device gear rack driving
Billet cutting method With walking-type flame cutting machine
Roller table before cutting chained grouping centralized frequency to drive
Roller table after cutting chained grouping centralized frequency to drive
End roller table chained grouping centralized to drive
Billet out method Hydraulic billet pusher—fixed cooling bed
Gross capacity of CCM’s system about 90kw

High quality steel scrap CCM machine for foundary and steel plant/ CCM / continuous casting machineHigh quality steel scrap CCM machine for foundary and steel plant/ CCM / continuous casting machine

Main Features

1. Easy Operate, Minimum maintenance & down time
2. Specially hardened material for longer service life > 8 hrs /day
3. Innovative design, low power consumption
4. Heavy duty perform under harsh working condition.
5. OEM, World class Continuous Casting machine and foundry machinery
6. High productivity & optimum quality

FQA

Q : Are you trading company or manufacturer?
A: We are manufacturer.

Q:How long is your delivery time?
A:Generally it is 30 days, it is according to quantity requires.

Q:What is the term of payment?
A: Payment <=1000USD, 100% in advance. Payment >=1000USD, 30% T/T in advance, balance before shipment.

Q:Do you have any Oversea Project?
A: Yes, we have service over 20 countries for their Plant set up Project.

If you are interested in this equipment, please don't hesitate to contact us!
If the machine is not suitable for your plant, please e-mail us the following information::

1. What’s the quality standard of billet do you want to casting? Is it common carbon steel or low carbon steel?
2. What’s the billet size and length?
3. Do you have melting furnace? If yes, how many tons of furnace with how many quantity?
4. What’s the capacity per hour?

According to your information, we will offer high efficiency design and best price for it.
