1/2.3 4.3mm 14Megapixel M12x0.5 Mount Low-Distortion Board Lens, Economic 4.3mm non-distortion lens
1/2.3 4.3mm 14Megapixel M12x0.5 Mount Low-Distortion Board Lens, Economic 4.3mm non-distortion lens
1/2.3 4.3mm 14Megapixel M12x0.5 Mount Low-Distortion Board Lens, Economic 4.3mm non-distortion lens
1/2.3 4.3mm 14Megapixel M12x0.5 Mount Low-Distortion Board Lens, Economic 4.3mm non-distortion lens
1/2.3 4.3mm 14Megapixel M12x0.5 Mount Low-Distortion Board Lens, Economic 4.3mm non-distortion lens
1/2.3 4.3mm 14Megapixel M12x0.5 Mount Low-Distortion Board Lens, Economic 4.3mm non-distortion lens
Specifications
Model Number :
123043MP 123043MPF
Place of Origin :
China
MOQ :
100 pcs
Payment Terms :
T/T, Western Union, MoneyGram, Paypal
Supply Ability :
Samples available
Delivery Time :
2-7 work days
Packaging Details :
Standard
Camera Lens :
CCTV Video Lens
Optical Lens :
S mount low-distortion wide-angle Lens
Brand Name :
CCOM LENS
Description

1/2.3" 4.3mm 14Megapixel s-mount low-distortion lens for scanners/HD cameras, 4.3mm 4K megapixel lens for Drones/Gopros/UAVs...

Model: 123043MPF
Sensor: 1/2.3"
Max image circle: Ø 8.1mm
Focal length: 4.3mm
Resolution: 14MP
F/No.: 2.8
B.F.L.: 3.62mm
F.B.L.: 2.82mm
T.T.L.: 22.00mm
F.O.V: 82°(D) x 72°(H) x 56°(V)
Distortion(TV-DVST): <-1.2%
Mount: M12*P0.5
Construction: 4G2P+IR
RELATIVE ILLUMIMATION: >80%
CUT FREQUENCY AT50%: λ=650±10nm

1/2.3

1/2.3

Tips:
- ***MP: without IR-Cut filter
- ***MPF: with IR-Cut filter
- 650nm/850nm/940nm IR filter optional
