Metal box switching power supply 200W 250W 350W 360W 400W 500W LED light switching power supply
Metal box switching power supply 200W 250W 350W 360W 400W 500W LED light switching power supply
Metal box switching power supply 200W 250W 350W 360W 400W 500W LED light switching power supply
Metal box switching power supply 200W 250W 350W 360W 400W 500W LED light switching power supply
Metal box switching power supply 200W 250W 350W 360W 400W 500W LED light switching power supply
Metal box switching power supply 200W 250W 350W 360W 400W 500W LED light switching power supply
Metal box switching power supply 200W 250W 350W 360W 400W 500W LED light switching power supply
Metal box switching power supply 200W 250W 350W 360W 400W 500W LED light switching power supply
Metal box switching power supply 200W 250W 350W 360W 400W 500W LED light switching power supply
Metal box switching power supply 200W 250W 350W 360W 400W 500W LED light switching power supply
Specifications
Brand Name :
BTB
Model Number :
S-350-12
Certification :
CE ,CCC,
Place of Origin :
China
MOQ :
100pcs
Price :
$2.0-$10.00
Payment Terms :
T/T PAYPAL WEST UNION, L/C, MoneyGram, Western Union
Supply Ability :
10000000pcs
Delivery Time :
3-5days
Packaging Details :
Paper box
Color :
silvery
Warranty :
3 years
OEM :
yes
Packing :
PE bags+ white paper box
Description

Metal box switching power supply 200W 250W 350W 360W 400W 500W LED light switching power supply

Features:
High efficiency, high reliability and low cost
For AC power supply input global
100% full load and machine test
Protection characteristics: short circuit/overload/pressure
PWM control and adjustment
Built-in dc electric fan forced air cooling
Built-in fan switch control
Working frequency 25 KHz
3 year warranty
Size: 215*115*50mm(L*W*H)
model S-250-5 S-300-7.5 S-350-12 S-350-13.5 S-350-15 S-350-24 S-350-27 S-350-48
output Dc output voltage 5V 7.5V 12V 13.5V 15V 24V 27V 48V
Output voltage tolerance ±2% ±2% ±1% ±1% ±1% ±1% ±1% ±1%
Rated output current 50A 40A 29A 25.8A 23.2A 14.6A 13A 7.3A
Output current range 0-50A 0-40A 0-29A 0-25.8A 0-23.2A 0-14.6A 0-13A 0-7.3A
Output power 250W 300W 348W 348.3W 348W 350.4W 351W 350.4W
Ripple and the noise 150mVp-p 150mVp-p 150mVp-p 150mVp-p 150mVp-p 150mVp-p 200mVp-p 240mVp-p
Dc voltage adjustable scope -10%,+12% ±20% -16%,+10% -12%,+11% -10%,+20% -16%,+10% -4%,+18% -15%,+17%
Start, rise, keep time 200ms,50ms,20ms Loaded with
input Input voltage range 90~132 VAC/180~264VAC 47~63 Hz;The switch choice
254~370VDC
Exchange input current 6.5A/115 V 4A/ 230 V
efficiency 74% 76% 76% 79% 78% 81% 82% 83%
Impulse current Cold start current
50A/115V 50A/230V
Leakage current <3.5 mA/240VAC
Protection characteristics Overload protection 105%~135%
Protection way: current limiting, automatic recovery
Overvoltage protection 115%~135%
Protection way: voltage limitation, automatic recovery
Fan on/off control RT3 acuity 55 ℃ fan open more than 45 ℃, wind 80 ℃ quartile organs, the cut off output (5 ~ 7.5 V)
RT3 acuity 65 ℃ and 55 ℃, fan open more than 80 ℃, the authorities: cut off output (12 to 15 V)
RT3 acuity 70 ℃ open more than 60 ℃ fan, wind, 85 ℃ cut off: authorities output (24 to 48 V)
environment Working temperature, humidity -10℃~+60℃;20%~90 %RH
Keep temperature, humidity -20℃~+85℃;10%~95 %RH
Vibrate resistance 10~500Hz,2G 10min./ 1 cycle time, 60 minutes, the axis
security Compression sex Input/output: 1.5 KVAC input and between to KVAC output and the earth: 1.5:0.5 KVAC
Insulation resistance Between the input and output, the input and output, and ground: 100 M / 500 VDC Ohms
standard Safety standards Accord with
UL1950
EMC standard Drsign refer to FCC Part15 J Conduction Class A
other weight 1.1.5Kg
packaging 12pcs/14.3Kg/0.93CUFT

Metal box switching power supply 200W 250W 350W 360W 400W 500W LED light switching power supply

Welcome to OEM/ODM

Free sample

Sample time : 3-5days

Delivery time:7-10days

Trade terms: FOB shenzhen

Payment : T/T ,L/C,PAYPAL ,Western Union

All product warranty 3 years(One years damage manufacture one to one exchange.)

Printing you LOGO and stick you modle also ok .
