96W 48V2A AC DC desktop switching power supply adapter/adaptor for LED strip light
96W 48V2A AC DC desktop switching power supply adapter/adaptor for LED strip light
96W 48V2A AC DC desktop switching power supply adapter/adaptor for LED strip light
96W 48V2A AC DC desktop switching power supply adapter/adaptor for LED strip light
96W 48V2A AC DC desktop switching power supply adapter/adaptor for LED strip light
96W 48V2A AC DC desktop switching power supply adapter/adaptor for LED strip light
96W 48V2A AC DC desktop switching power supply adapter/adaptor for LED strip light
96W 48V2A AC DC desktop switching power supply adapter/adaptor for LED strip light
96W 48V2A AC DC desktop switching power supply adapter/adaptor for LED strip light
96W 48V2A AC DC desktop switching power supply adapter/adaptor for LED strip light
96W 48V2A AC DC desktop switching power supply adapter/adaptor for LED strip light
96W 48V2A AC DC desktop switching power supply adapter/adaptor for LED strip light
Specifications
Brand Name :
BTB
Model Number :
B-001500200
Certification :
CE CB UL FCC SAA GS ROHS CCC KC
Place of Origin :
China
MOQ :
500PCS
Price :
$3.0-$10.00
Payment Terms :
T/T,L/C,Western union,Cash,Paypal
Supply Ability :
200000pcs/week
Delivery Time :
7-10days
Packaging Details :
PE bags + paper box
Description

96W 48V2A AC DC desktop switching power supply adapter/adaptor for LED strip light

Product Description:

Output power range 48V 2A
Input Rated Voltage 100Vac~240Vac
Input Frequency Range 50Hz~60Hz
Input Current less than 0.5A
Input Inrush Current less than 50A
Efficiency 86%(MIN)at Rated Voltage
DC Output Voltage 48v± 5%
DC Output Current 10A (Optional)
DC Output Power 120w (optional)
Leakage Current less than 5mA
Standby power less than 0.5w
DC connector 5.5*2.1*10mm (optional)
DC cable 1.2m 2464 UL 18AWG cable (optional)
Ripple and Noise less than 120Mv at full road with 20MHz bandwidth
Turn On Delay Time less than 3S (AC:110V and full load)
Certificates CE GS UL/CUL FCC ROHS SAA PSE TUVGS KC CLASS2 UL1310
Dielectric Voltage A IEC320 three pin input---output(FG)3000Vac one minute
Safety protection output voltage protection (150%-180% rated output current)
output current protection (150%-180% rated output current)
short current protection
Operating Temperature -10°C - +45°C
Storage Temperature -20°C - +40°C
Safety Standard EN60950-1 UL60950-1 ESD (EN61000 3-3)
CAS (60950 ITE/TE) FCC Part 15 subpart B Class B
ISO 9001: 2008

Input Rated Voltage : 100Vac~240Vac
Efficiency : 85%(MIN)at Rated Voltage
Output: 12V 5A
Output power : 60W
Ripple and Noise : <120Mv at full road with 20MHz bandwidth
Turn On Delay Time: <3S (AC:110V and full load)
Safety protection : over voltage and current protection for ac/dc power adapter
Leakage Current: <5mA
DC cable length: 1.5 meters
Operating Temperature: 0°C----+60°C
Storage Temperature: -20°C----+85°C
Certificate: CE GS TUV UL/CUL FCC ROHS,SAA,PSE,C-TICK
Application: CCTV camera ,and LCD minitor , mobile phone ,pos machine ,ac/dc power adapter and so on

24W~36W DESKTOP SERIES
Model InputVoltage Power OutputVoltage OutputCurrent ACInletType
S-00240200-S10 100-240VAC 24W 12V 2A C8,C6,C14
S-00150160-S10 100-240VAC 24W 15V 1.6A C8,C6,C14
S-00240100-S10 100-240VAC 24W 24V 1A C8,C6,C14
S-00090300-S10 100-240VAC 27W 9V 3A C8,C6,C14
S-00240125-S10 100-240VAC 30W 24V 1.25A C8,C6,C14
S-00300100-S10 100-240V AC 30W 30V 1A C8,C6,C14

96W 48V2A AC DC desktop switching power supply adapter/adaptor for LED strip light

36W~65W DESKTOP SERIES
Model InputVoltage Power OutputVoltage OutputCurrent ACInlet
S-00090400-S10 100-240VAC 36W 9V 4A C8,C6,C14
S-00090500-S10 100-240VAC 45W 9V 5A C8,C6,C14
S-00090600-S10 100-240VAC 54W 9V 6A C8,C6,C14
S-00120300-S10 100-240VAC 36W 12V 3A C8,C6,C14
S-00120400-S10 100-240VAC 48W 12V 4A C8,C6,C14
S-00120500-S10 100-240V AC 60W 12V 5A C8,C6,C14
S-00150300-S10 100-240V AC 45W 15V 3A C8,C6,C14
S-00150400-S10 100-240V AC 60W 15V 4A C8,C6,C14
S-00190200-S10 100-240V AC 38W 19V 2A C8,C6,C14
S-00190300-S10 100-240V AC 48W 19V 3A C8,C6,C14
S-00190316-S10 100-240V AC 60W 19V 3.16A C8,C6,C14
S-00190342-S10 100-240V AC 65W 19V 3.42A C8,C6,C14
S-00240200-S10 100-240V AC 48W 24V 2A C8,C6,C14
S-00240250-S10 100-240V AC 60W 24V 2.5A C8,C6,C14

96W 48V2A AC DC desktop switching power supply adapter/adaptor for LED strip light

72W~96W SERIES
Model InputVoltage Power OutputVoltage OutputCurrent ACInlet
S-00120600-S10 100-240VAC 72W 12V 6A C8,C6,C14
S-00120700-S10 100-240VAC 84W 12V 7A C8,C6,C14
S-00240300-S10 100-240VAC 72W 24V 3A C8,C6,C14
S-00240400-S10 100-240VAC 96W 24V 4A C8,C6,C14

96W 48V2A AC DC desktop switching power supply adapter/adaptor for LED strip light

Applications:

24V 1.5A AC DC Power Adapter Desktop Adapter Power Supply Laptop Adapter

can be applied in security equipments, portable equipments, telecommunication equipments, consumer equipments, and other equipments.

  • Security equipment: monitoring camera, hard disk video recorder, security system, control equipment, monitoring equipment, etc.
  • Portable equipment: portable DVD, radio, mobile hard disk box, portable tools, charger, lithium ion battery, game machine, language repeater, walkman, digital products, tablet PC, etc.
  • Telecommunication equipment: router, microprocessor system, ADSL equipment, telephone composite aircraft, hub, telecommunications terminal equipment, cell phone, etc.
  • Consumer equipment: LCD TV, HD player, DVD players, digital photo frame, electronic refrigerator, acoustics, LED lamps and lanterns, small power electric appliances, electric tools, audio-video products, mini TV, decorative lighting, massager, LED lighting, electric bicycle battery charger, small size LCD TV and set top box, air cleaner, LCD, computer monitor, etc.
  • Other equipment: industrial automation control, military equipment, scientific research equipment, industrial control equipment, electric power equipment, medical equipment, semiconductor refrigeration and heating, computer chassis, instrument power supply, printer, testing equipment, and almost any other portable type equipment.

96W 48V2A AC DC desktop switching power supply adapter/adaptor for LED strip light96W 48V2A AC DC desktop switching power supply adapter/adaptor for LED strip light

Welcome to OEM/ODM

Free sample

Sample time : 3-5days

Delivery time:7-10days

Trade terms: FOB shenzhen

Payment : T/T ,L/C,PAYPAL ,Western Union

All product warranty 3 years(One years damage manufacture one to one exchange.)

Printing you LOGO and stick you modle also ok .

Credit is the basis , Quality is the first

Power adapter ,Charger ,Power supply Manufacture

Skype:beryl--qin

What's app: 86 13412619588

QQ:1767294269

Wechat: beryl18

www.btbadapter.com

96W 48V2A AC DC desktop switching power supply adapter/adaptor for LED strip light96W 48V2A AC DC desktop switching power supply adapter/adaptor for LED strip light96W 48V2A AC DC desktop switching power supply adapter/adaptor for LED strip light
