Specifications
Place of Origin :
China
Brand Name :
KINGTONE OR OEM
Certification :
CE, RoHS, VDE, UL, CUL, LPCB
Model Number :
18 AWG 2 Cores Audio Speaker Cable
MOQ :
30KM
Packaging Details :
500FT, 1000FT, Plastic / Wooden Spool, Carton
Delivery Time :
Normally 15 days
Payment Terms :
T/T, L/C
Supply Ability :
50*20’GP / Month
Conductor :
Stranded Bare Copper
Insulation :
CMR Rated PVC
Rip-cord :
Yes
Jacket :
CMR Rated PVC
Color :
Yellow, White, Purple
Package :
500FT, 1000FT, Plastic / Wooden Spool, Carton
Description

18 AWG 2 Cores Conductor Professional Audio Cable with 7 × 26 Stranded OFC

Quick Detail:

  • Audio Speaker Cable
  • 18 AWG (7×26) Conductor
  • 2 Core Stranded Conductor
  • Bare Copper Conductor
  • PVC, UL CMR Rated
  • 500FT, 1000FT, Plastic / Wooden Spool, Carton

Description:

Speaker wire is used to make the electrical connection between loudspeakers and audio amplifiers.

Modern speaker wire consists of two or more electrical conductors individually insulated by plastic

(such as PVC, PE or Teflon) or, less commonly, rubber. The two wires are electrically identical,

but are marked to identify the correct audio signal polarity. Most commonly, speaker wire

comes in the form of zip cord.



The effect of speaker wire upon the signal it carries has been a much-debated topic in the

audiophile and high fidelity worlds. The accuracy of many advertising claims on these points

has been disputed by expert engineers who emphasize that simple electrical resistance is

by far the most important characteristic of speaker wire.

KINGTONE using best raw material and best worker to produce Speaker wire to meet high

performance in practical application.Because of good managing methods, KINGTONE’S

price of Speaker wire is not high although our quality is really high.

KT1604 Audio Cable 18AWG 2C Stranded Bare Copper PVC CMR (UL) Speaker Cable
Construction Parameters:
Conductor Stranded 18AWG (7×26) Bare Copper
No. of Conductor 2
Nom. Insulation Thickness 0.008"/0.20mm PVC CMR
Nom. Jacket Thickness 0.017"/0.43mm PVC CMR
Overall Cable Diameter 0.156"/3.96mm PVC CMR
Approximate Cable Weight 16.6 Lbs/1000ft
Flame Rating UL 1666 Riser Flame Test
Electrical Characteristics:
Nom. D.C. R. Resistance @ 20°: 6.2 ohms per 1000ft
Temperature Rating -20° C to 60° C
Operating Voltage 300 V RMS Max
Capacitance Between
Conductors@1KHz
30 pF/ft Nom.
Insulation Colors Black, Red
Jacket Colors Grey, Black, Brown, White
RoHS YES
Order Informations:
Marking

KINGTONE KT1604 AUDIO CABLE 18AWG 2C Stranded Bare

Copper PVC
CMR (UL) Speaker Cable XXX M/FT

Package 500FT/Pull Box, 1000FT/Wooden Spool, Pallet
Delivery time Normally 15 days after received the deposit.
Online Service:
Skype kingtone3
ICQ 246632889

Competitive Advantage:

1, From raw materials to final products, we perform intense quality checks to maintain our product quality:

A, Incoming material inspected by QC.

B, Manufacturing Process Control

C: Workers trained daily/weekly/monthly

D: Work instructions manual at each work station

E: 5S system implemented

F: Machine maintenance procedure

G: Quality Control and Final Inspection

The QC staff will check the material, process product

and final product according to the specification or test procedure.

2, Our R&D efforts center on reinforcing and developing element technologies

needed to support the future growth and success for customers and KINGTONE.

3, We know customers have urgent needs.

We are skilled at effective communication to interact with customers.

In order to provide prompt service, we can answer for you 7*24 hours.

4, We can Quickly and professionally answer for the inquire

5, More than 1000 kinds of cable, connectors and assembles can be produce and organized from us

6, Intime delivery
