Specifications
Brand Name :
CDS SOLAR
Model Number :
PS100kW-700kWh
Place of Origin :
Liaoning, China
Price :
$245,320.34/Sets >=1 Sets
Supply Ability :
100 Set/Sets per Month
Description

off grid pv panel system solar storage 100kW-700kWh power system with 6000cycles and 10years warranty

100kw To 700kwh Power Storage System 60hz Solar Off Grid Pv Battery Storage

Product Descriptions

100kW-700kWh Energy Storage System

Model No.

PS100kW-700kWh

Lithium Battery

Model No.

PS100KW-350KWh

Battery Capacity

700 kWh

Battery Type

Lithium Iron Phosphate Battery

Battery Warranty

5000 cycle times or 5 Years (DOD90% & 25)

AC Input (Charging)

AC Input Voltage

400 / 480 VAC

Power Factor

-1~+1

AC Input Frequency

50Hz / 60Hz ± 2.5Hz

Max Charge Power

100 kW

Max Efficiency

98.2%

AC Output (Discharging)

Rated AC Output Power

100kW

AC Output Voltage

400 / 480 VAC

AC Output Frequency

50 / 60Hz ± 2.5Hz

Max Efficiency

98.2%

PV Input (Optional)

Max PV Input Power

110kWp

MPPT Input Voltage Range

450~850 VDC

MPPT Number

1 / 2

MPPT Efficiency

99.50%

Max Efficiency

99.01%

Unique Function

Grid-Level Function

Peak shaving and valley filling for electric network

Operational Mode

Off-Grid Mode / On-Grid Mode / On & Off grid Mode (Optional)

UPS Function

YES

Black Start Function

YES

Communication Mode

Modbus TCP/IP

Communication Interface

LAN, RS485, CAN

General

Working Condition

Temperature range -20~50, Humidity range 0~95%

Noise and Altitude

70dB, <3000m

Size of PS100kW-700kWh

20 foot container

Weight of PS100kW-700kWh

15 tons

Certification

CE, TUV, IEC, UL, ETL

Email : cmo@cds-solar. com Whatsapp : +86 18340803630 Facebook : Cds solar

100kw To 700kwh Power Storage System 60hz Solar Off Grid Pv Battery Storage

Power Station supports multiple battery technologies and configurations for maximum application and supply chain flexibility. The modular, pre-engineered design simplifies project development and enables repeatable deployment for maximum project velocity.

100kw To 700kwh Power Storage System 60hz Solar Off Grid Pv Battery Storage

PowerStation provides a flexible, pre-engineered energy storage solution consisting of a standard ISO container with integrated electrical, mechanical, and thermal management features. Using advanced, patent-pending technologies to ensure safe operation and optimized performance, the container delivers a standardized system infrastructure for customer-supplied Tier 1 lithium-ion batteries.
