High Power Long Distance Feed Screw Conveyor For Sand Grain Loose Materials
High Power Long Distance Feed Screw Conveyor For Sand Grain Loose Materials
High Power Long Distance Feed Screw Conveyor For Sand Grain Loose Materials
High Power Long Distance Feed Screw Conveyor For Sand Grain Loose Materials
High Power Long Distance Feed Screw Conveyor For Sand Grain Loose Materials
High Power Long Distance Feed Screw Conveyor For Sand Grain Loose Materials
Specifications
Brand Name :
Green Eco-Equipment
Certification :
ISO9001:2008/CE
Place of Origin :
Henan, China
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
20 sets per month
Delivery Time :
10~15 work days after receiving fullpayment.
Packaging Details :
In Bulk/Tray/Wooden Case/As Customer's Requirement
Condition :
New
Warranty :
1 year
Material :
Carbon Steel/ Stainless Steel
Voltage :
220V/380V/As cuntomer's request
Material Feature :
Heat Resistant
Structure :
Conveyor System
Application :
Cement, powder, coal, grain, etc.
After-sales Service Provided :
Field installation, commissioning and training
Description

Long Distance Screw Auger Conveyor Feeder For Sand Grain Loose Materials

Product Description

LS Type Screw Conveyoris the new generation production that replaced of the GX type screw conveyor. The head and tail bearing have been moved outside from housing. The LS screw conveyor is easy to install and maintain by using sliding bearing, dust proof seal and sliding block.This product has the advantages of high reliability, long service life and strong adaptability.And Long Distance Screw Auger Conveyor Feeder is designed based on LS type screw conveyor with high power, which is much more suitable for long distance conveying bulk materials in low cost.

It is suitable for continuously conveying loose materials such as powder, granular and small material, including: clay powder, coal powder, cement, sand, grain, small coal, pebble, cast iron powder, etc.However, it is not suitable for materials with high viscosity and easy condensation.

Main Parameters

LS type 160 200 250 315 400 500 630 800 1000
GX type 200 250 300 400 500
Screw diameter(mm) 160 200 250 315 400 500 630 800 1000
Sc Screw pitch(mm) 160 200 250 315 355 400 450 500 560
Rotate speed(r/min) 60 50 50 50 50 50 50 45 35
Capacity (m³/h) 7.6 11 22 36.4 66.1 93.1 160 223 304
Pd1=10m(kw) Power 1.5 2.2 2.4 3.2 5.1 5.1 8.6 12 16
Pd1=30m(kw) Power 2.8 3.2 5.3 8.4 11 15.3 25.9 36 48

Advantages

1. Large bearing capacity, safe and reliable.
2. Strong adaptability, easy installation and maintenance, long service life.

3. Flexible technological arrangement, easy to be installed, dismantled and moved, and safe operation.
4. The discharge end is equipped with cleaning device, low noise, strong adaptability, in and out of the mouth position arranged flexibly.

5. Excellent seal performance and transport efficiency.
6. Small screw diameter with impact structure, high rotation speed which maintains large capacity.
7. Completely closed structure, no pollution to the environment, the working environment has been improved.

Applicaiton

The screw conveyor is widely used for conveying powder, granule, and small block materials, such as: cement, sand, grain, gravel, chemical, fertilizer, coal, etc. And the shaftless screw conveyor is suitable for continuous conveying of materials with thick, easy winding, easy caking and poor fluidity, such as: sludge, stalk, and wood chips, etc.

High Power Long Distance Feed Screw Conveyor For Sand Grain Loose Materials

Packing & Shipping

Well-designed packing and transportation ensure that the products can be delivered intactly to our customers.

High Power Long Distance Feed Screw Conveyor For Sand Grain Loose Materials

Field Usage

High Power Long Distance Feed Screw Conveyor For Sand Grain Loose Materials
