Cast Steel Apron Feeder Equipment Apron Conveyor 800t/h
Cast Steel Apron Feeder Equipment Apron Conveyor 800t/h
Cast Steel Apron Feeder Equipment Apron Conveyor 800t/h
Cast Steel Apron Feeder Equipment Apron Conveyor 800t/h
Specifications
Brand Name :
Green Eco-Equipment
Model Number :
BW1000
Certification :
ISO9001:2008/CE
Place of Origin :
Henan, China
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
10 sets per month
Delivery Time :
10~15 work days after receiving fullpayment.
Packaging Details :
In Bulk/Tray/Wooden Case/As Customer's Requirement
Product name :
Apron Feeder
Material :
Cast Steel
Voltage :
220V/380V/As Customer's Request
Material Feature :
Heat Resistant
Capacity(t/h) :
20-800t/h
Dimension(L*W*H) :
As Customer's Request
Type :
Apron feeder
Suitable Material :
Cement, Coal, Gravel, Stone
Application :
Construction works, Mining, Power Plant, Metallurgical Industry
Warranty :
2 Years
After-sales Service Provided :
Field installation, commissioning and training
Description

Good performance Apron Feeder Equipment / Apron Conveyor

Product introduction

The apron feeder conveyor is a series of conveying equipment that carries a solid moving material to support the bulk solid material by a series of metal phosphor plates supported on the roller chain. Phosphor plate conveyors are available in three types: horizontal, inclined and horizontally inclined. The working principle is basically the same. The movement of materials is formed by the phosphor plate. The slat conveyor mechanism is simple, has a wide application range, has a high conveying capacity, low running resistance, convenient installation and maintenance, and long service life. It can not only be transported horizontally, but also can be conveyed obliquely; it can be multi-point feeding, and the equipment process layout is flexible.

Cast Steel Apron Feeder Equipment Apron Conveyor 800t/h

Technical parameter

Model

Plate width

(mm)

 Head to tail shaft center distance(mm)

Particle size

(mm)

Speed

(m/s)

Capacity

(t/h)

Power

(kw)

Reference weight

(kg)
WBL100-6 1000 6000 ≤500 0.01-0.2 ≤130 11 15000
WBL120-6 1200 6000 ≤600 0.01-0.2 ≤150 11 16000
WBL125-6 1250 6000 ≤600 0.01-0.2 ≤160 11 18000
WBL140-8 1400 8000 ≤700 0.01-0.2 ≤200 22 29000
WBL150-5 1500 5000 ≤700 0.01-0.2 ≤288 15 18000
WBL160-6 1600 6000 ≤800 0.01-0.2 ≤400 22 25000

Application

Apron feeder is wildly used in mining, building materials, metallurgy, coal, chemical and other industries for transporting sharp, burning, corrosive material.

Cast Steel Apron Feeder Equipment Apron Conveyor 800t/h

Our advantages on Apron feeder

1. Excellent installation team or installation service for you;
2. Provide you with operating and training services;
3. Help with the equipment commissioning and solve problems in trial operation;
4. Check before acceptance of single equipment or whole production line;
5. Service items including follow-up visit, customer satisfaction surveys and so on;
6. Timely provide you with necessary accessories after acceptance;
7. Provide you with warranty services of repair, replacement and refund if conditions are fulfilled.
8. Help you solve other problems.

Sucessful case

Cast Steel Apron Feeder Equipment Apron Conveyor 800t/h
