Cemented Tungsten Carbide Sheet Fine Thermal Shock Resistance Long Usage Lifetime
Cemented Tungsten Carbide Sheet Fine Thermal Shock Resistance Long Usage Lifetime
Specifications
Brand Name :
Weiye
Model Number :
customized
Certification :
ISO9001:2000; PVOC
Place of Origin :
Zhuzhou，Hunan，China（mainland）
MOQ :
5kg
Price :
Negotiable
Payment Terms :
Negotiable
Supply Ability :
40000 kg per month
Delivery Time :
20-30 days depend on quantity
Packaging Details :
Meeting customers's requirement
Material :
wolfram
finished :
grinding，blank
HS code :
843143100
grain :
Ultra-fine grain sizes
feature :
100% virgin raw material
Chemical :
92% Wc, 8%Co
Description

Wc Plus Co Cemented Carbide Plate Widely Using In Cutting Making Factory

Description:

Tungsten carbide plate is also known as cemented sheet, carbide sheet. It is one of many materials of cemented carbide and is named for its shape as a rectangular plate (or square).

Tungsten Carbide Plate is used for cutting general wood cutters, hard wood cutters, plastic and tobacco, as well as to making drawing dies, wear parts and module core for punching parts and automatic press and etc.

Our advantages

The use of strict screening, high purity, high-quality raw materials.
Advanced production equipment and unique manufacturing technology to achieve stable quality and short delivery cycle.
Perfect process and ISO9001 quality certification system to ensure product control lability and stability.
Adapt to market demands, develop new materials and optimize product performance.

Great and Application:

Grade Hardness(HRA) TRS N/mm2 Density g/cm3 Application recommend
YG6X 92 1800 14.9 it can be used to make steel wire,non-ferrous metal wire or bar material with less
than 6.0mm diameter.
YG6 90.5 2000 14.9 it can be used for steel wire,non-ferrous metal and alloy bars under 20mm diameter,and can be also used for drawing pipes with diameter of less than 10mm.
YG8 90 2200 14.7 can be used in steel,non-ferrous metal and alloy bars and pipes,also can be used in manufactureing machinery parts,tools and vulnerable parts.
YG8.2 89 2000 14.6
YG8L 89 2000 14.6
YG11 88.5 2300 14.4 it can be used fo rhigh compression steel rod and steel pipe drawing,and the top hammer,perforation and stamping die of working under great stress.
YG15 87 2600 14
YL50 87 2600 14.4
YG20 85 2800 13.6 it can be used for stamping die,such as punching watch parts,stamping battery
shell,tooth paste mould,small size steel ball,screw,nut,etc.
YG20C 83.5 2800 13.6 it can be used in standard parts,bearings,tools and other industries for cold forging,cold pressing mould,warhead and shell stamping dies.
TL40.5 82 3000 13.3

Standard Parameter:

type tolerance(mm)
L B H
7×5×2.4 ±0.5 ±0.3 ±0.4
9×5×2.4 ±0.5 ±0.3 ±0.4
9×6×1.5 ±0.5 ±0.5 ±0.3
12×5×2.4 ±0.6 ±0.3 ±0.4
12×6×1.5 ±0.6 ±0.5 ±0.3
12×10×2.2 ±0.6 ±0.5 ±0.4
12×12×5 ±0.6 ±0.6 ±0.4
14×10.5×2 ±0.6 ±0.6 ±0.3
15×8×2 ±0.6 ±0.5 ±0.3
17×5×2.4 ±0.6 ±0.3 ±0.4
17×8.2×25 ±0.6 ±0.5 ±0.8
20×5×5 ±0.6 ±0.3 ±0.4
20×8×6 ±0.6 ±0.5 ±0.5
25×20.5×5.2 ±0.6 ±0.8 ±0.5
25.3×6.3×4 ±0.8 ±0.5 ±0.4
27×6×4 ±0.8 ±0.5 ±0.4
27×9×4 ±0.8 ±0.5 ±0.4
27×14.5×14 ±0.8 ±0.6 ±0.7
28×9.3×4 ±0.8 ±0.6 ±0.4
30×12×5 ±0.8 ±0.6 ±0.4
30×26×4 ±0.8 ±0.8 ±0.4
35×5×3.5 ±0.8 ±0.3 ±0.4
