Specifications
Brand Name :
Weiye
Model Number :
customized
Certification :
ISO9001
Place of Origin :
Zhuzhou，Hunan，China（mainland）
MOQ :
5 kg
Price :
Negotiable
Payment Terms :
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
40000 kg per month
Delivery Time :
5-30 days depend on quantity
Packaging Details :
Meeting customers's requirement
material :
tungsten carbide
product name :
tungsten carbide strip
size :
Length: 100~1500mm, Thickness: 1.0~36mm, Wide: 1.0~36mm
Grade :
YG6, YG8, YL10.2, YG10X, YG15, YG20 etc
Hardness :
89-93.6 HRA more or less
Feature :
High quality, high performance, high precision
Description

ISO Tungsten Carbide Plates , Square Carbide Blanks Can Do 1500mm Length

Our tungsten carbide strips are very suitable for woodworking tools, plane cutter, hob cutter, sub-cutter etc.

We use advanced molding process in order to produce extremely length 1500mm, extremely slim 1mm carbide flat to meet our clients' requirements.

ISO Tungsten Carbide Plates , Square Carbide Blanks Can Do 1500mm Length

Specification

L*W*T

 L(mm) W(mm) T(mm) Tolerance
100*W*T 100 4~100 1.0~36 L W T
150*W*T 150 4~150 1.0~36 +/-1.5% +/-2.5% +/-2.5%
230*W*T 230 8~60 1.0~36 +/-1.5% +/-2.5% +/-2.5%
250*W*T 250 8~60 1.2~36 +/-1.5% +/-2.5% +/-2.5%
270*W*T 270 8~60 1.2~30 +/-1.5% +/-2.5% +/-2.5%
320*W*T 320 8~60 1.2~30 +/-1.5% +/-2.5% +/-2.5%
330*W*T 330 10~40 1.2~30 +/-1.5% +/-2.5% +/-2.5%
410*W*T 410 10~40 1.2~10 +/-1.5% +/-2.5% +/-2.5%
510*W*T 510 10~40 1.2~10 +/-1.5% +/-2.5% +/-2.5%
610*W*T 610 12,17,20,32 1.2~10 +/-1.5% +/-2.5% +/-2.5%
710*W*T 710 12,17,20,32 1.2~10 +/-1.5% +/-2.5% +/-2.5%
855*W*T 855 12,17,20,32 1.5~10 +/-1.5% +/-2.5% +/-2.5%
1100*W*T 1100 12,17,20 1.5~10 +/-1.5% +/-2.5% +/-2.5%
1500*W*T 1500 12,17,20 1.5~10 +/-1.5% +/-2.5% +/-2.5%

Can produce angle strips according to client's requirements.

ISO Tungsten Carbide Plates , Square Carbide Blanks Can Do 1500mm Length

Grade and Recommend Application:

Grade Co% Grain

Hardness

HRA

Density

g/cm³

TRS

Mpa

elastic modulus

Gpa

thermal expansion coefficient

10-6/0C
ST05B 6.5 1.0 91.5 14.8 2800 525 4.9
ST10C 7.0 1.0 90.5 14.8 2800 520 5
ST10B 8.0 1.0 91.0 14.6 3000 510 5.1
ST03F 5.0 0.6 93.5 14.9 2600 540 4.8
ST10F 6.0 0.6 93.0 14.8 3000 530 4.9
ST15F 10.0 0.6 92.2 14.4 3300 490 5.4
ST12F 9.0 0.5 93.6 14.5 4000 510 5.3
ST05F 6.0 0.6 93.0 14.9 3200 530 4.9

ST05B:Suitable for processing solid wood, gray cast iron and other materials.

ST10C:It is suitable for processing solid wood, nonferrous metals and other materials.

ST10B:Suitable for processing solid wood, stainless steel and other materials.

ST03F:Cutting tools suitable for making brake materials, etc.

ST10F:It is suitable for making simple cutting tools.

ST15F:It is suitable for rough machining of hardened steel and so on.

ST12F:It is suitable for processing high speed steel and stainless steel.

ST05F:Super high hardness, suitable for bamboo and wood cutting tools.

Processing:

Powder preparation prescription according to the use requirements wet grinding mixing grinding drying screening adding molding agent drying screening after the preparation of mixture pelleting pressing molding sintering forming (blank) inspection packaging storage.

ISO Tungsten Carbide Plates , Square Carbide Blanks Can Do 1500mm Length

Feature:

Cemented carbide strips have excellent hardness, high hardness, good wear resistance, high modulus of elasticity, high compressive strength, good chemical stability (acid, alkali, high temperature oxidation), low impact toughness, low expansion coefficient, thermal conductivity and conductivity of iron and its alloys are similar.
