Specifications
Brand Name :
JinTaiPai
Model Number :
Various or Customized dimension available
Certification :
SGS
Place of Origin :
Hunan, China
MOQ :
1 - 1000 Kilograms, sample order acceptable
Price :
Negotiable, depends on carbide grade and quantity.
Supply Ability :
300 Ton/Tons per Month
Delivery Time :
7-25 days, depends on quantity.
Packaging Details :
Pack with shock resistance foam first in plastic box, and then carton boxes outside. Or pack according to your request
Payment Terms :
L/C, T/T, Western Union
Alloy Specification :
K01, K10, K20 carbide grade
Particle :
0.2-1.7um
Product name :
Customized k10 k20 k30 cemented carbide rods small tungsten carbide piece
Material :
100% virgin carbide material
Surface :
High Polished, h6
Certificate :
ISO
Color :
Silver Gray
Application :
Machinery Tools
Description

Customized k10 k20 k30 cemented carbide rods small tungsten carbide piece

End mills,reamers and gravers are recommended. Excellent performance for high speed cutting. Suitable for cutting hardened steel, aluminum alloy and Titanium alloy. We provide custom-made, near-net-shape, premium insert blanks in cemented carbide - also known as Tungsten carbide or solid carbide.

Material composition:
1.Physical Properties:
A) Hardness greater than or equal to 92.8 HRA；
B) Density greater than or equal to 14.2 g/cm³；
C) TRS greater than or equal to 4200 N/mm²；
D) Free of ETA phase condition；
E) No contamination by other materials；
F) Porosity = A00 / B00 / C00 ；
G) Uniform and consistent grain size. No grain size can be larger than specified.
H) Chromium carbide grain growth inhibitor only.
2.All the production, coatings are used in Germany, Switzerland, processing equipment；
3.It's proposed cutting less than 60HRC;

Properties of cemented carbide grades recommended rods

Grade

Chemical composition

Physical data

Grain size of WC(um)

WC

Co

Others

Density(g/cm³)

Hardness(HV3)

TRS(MPa)

YL10.1

93.5%

6.0%

0.5%

14.88-15.04

1580±50

2500

1.2-1.7

YL10.2

89.5%

10.0%

0.5%

14.4-14.55

1600±50

4000

0.8

YL10.5

89.7%

9.5%

0.8%

14.4-14.55

1550±50

3800

0.7-0.9

YL50

85.0%

15.0%

13.86-14.10

1095

2060

0.4-0.6

YU06

93.0%

6.0%

1.0%

14.7-14.8

2050

3000

0.2-0.4

YU08

91.0%

8.0%

1.0%

14.56-14.65

1900

4000

0.2-0.4

YU09

89.8%

9.0%

1.2%

14.36-14.50

1950

3900

0.2-0.4

YU12

87.0%

12.0%

1.0%

14.05-14.15

1750

4000

0.2-0.4

YF06

93.5%

6.0%

0.5%

14.86-14.96

1800

3800

0.4-0.6

YF08

91.4%

8.0%

0.6%

14.55-14.65

1800

3900

0.4-0.6

YG6X

93.5%

6.0%

0.5%

14.8-15.10

91

1560

1.0

YG8

92.0%

8.0%

14.6-14.9

89.5

1840

1.2-1.6

~ Customized Tungsten carbide products are available!

Customized K10 K20 K30 Cemented Carbide Rods Small Tungsten Carbide Piece

Type D(mm) Tol. Of diameter(mm) L(mm) Tol. Of diameter(mm)
￠1.0*330 1.0 +0.2~+0.45 330 0~+5.0
￠2.0*330 2.0 +0.2~+0.45 330 0~+5.0
￠3.0*330 3.0 +0.2~+0.45 330 0~+5.0
￠4.0*330 4.0 +0.2~+0.45 330 0~+5.0
￠5.0*330 5.0 +0.2~+0.45 330 0~+5.0
￠6.0*330 6.0 +0.2~+0.45 330 0~+5.0
￠7.0*330 7.0 +0.2~+0.45 330 0~+5.0
￠8.0*330 8.0 +0.2~+0.45 330 0~+5.0
￠9.0*330 9.0 +0.2~+0.45 330 0~+5.0
￠10.0*330 10.0 +0.2~+0.5 330 0~+5.0
￠11.0*330 11.0 +0.2~+0.5 330 0~+5.0
￠12.0*330 12.0 +0.2~+0.5 330 0~+5.0
￠13.0*330 13.0 +0.2~+0.5 330 0~+5.0
￠14.0*330 14.0 +0.2~+0.5 330 0~+5.0
￠15.0*330 15.0 +0.2~+0.6 330 0~+5.0
￠16.0*330 16.0 +0.2~+0.6 330 0~+5.0
￠17.0*330 17.0 +0.2~+0.6 330 0~+5.0
￠18.0*330 18.0 +0.2~+0.6 330 0~+5.0
￠19.0*330 19.0 +0.2~+0.6 330 0~+5.0
￠20.0*330 20.0 +0.2~+0.7 330 0~+5.0
￠21.0*330 21.0 +0.2~+0.7 330 0~+5.0
￠22.0*330 22.0 +0.2~+0.7 330 0~+5.0
￠23.0*330 23.0 +0.2~+0.7 330 0~+5.0
￠24.0*330 24.0 +0.2~+0.7 330 0~+5.0
￠25.0*330 25.0 +0.2~+0.7 330 0~+5.0
￠26.0*330 26.0 +0.2~+0.8 330 0~+5.0
￠27.0*330 27.0 +0.2~+0.8 330 0~+5.0
￠28.0*330 28.0 +0.2~+0.8 330 0~+5.0
￠29.0*330 29.0 +0.2~+0.8 330 0~+5.0
￠30.0*330 30.0 +0.2~+0.8 330 0~+5.0

Customized K10 K20 K30 Cemented Carbide Rods Small Tungsten Carbide Piece
Customized K10 K20 K30 Cemented Carbide Rods Small Tungsten Carbide PieceCustomized K10 K20 K30 Cemented Carbide Rods Small Tungsten Carbide Piece
