Round Carbide Milling Inserts , Tungsten Carbide Tool Inserts With Sharp Edge
Round Carbide Milling Inserts , Tungsten Carbide Tool Inserts With Sharp Edge
Specifications
Brand Name :
JinTai Pai
Model Number :
Various or Customized
Certification :
ISO standard
Place of Origin :
Hunan, China
MOQ :
1 - 49 Kilograms sample order acceptable
Price :
Negotiable, depends on carbide grade and quantity.
Supply Ability :
20 Ton/Tons per Month
Packaging Details :
Packed in Wooden case and inner in paper box.or we can package by your requirments.
Delivery Time :
7-25 days, depends on quantity.
Payment Terms :
L/C, T/T, Western Union
Product name :
Carbide Round Inserts
Alloy Specification :
YL10.2
Grade :
YG6/YG8/YG10X/YG20C
Material :
100% Virgin Tungsten Carbide
Application :
Mining
Performance :
Good wear resistance / High bending strength,
Package :
carton or as required
Description
Cemented carbide is a hard material used extensively as cutting tool material, as well as other industrial applications. It consists of fine particles of carbide cemented into a composite by a binder metal.

1. The edge is sharp.

2. Good wear resistance and long service life.

3. Special cutting blades for PCB board, circuit board, plastic, PVC board, etc.

4. Mainly used for knitting machine needle groove processing knife, printed circuit board V-groove cutting knife, special parts for glasses parts.

Features:
1. Stable mechanical properties
2. High weldability
3. Excellent Abrasion and corrosion resistance
4. High Impact resistance
5. Sand blasted surface, no peeling, no stratifying (delaminating), no cracking.

Grade information of tungsten carbide blank strip

Not all listed , OEM/ODM is welcome!
Any customized shape and dimension is acceptable!

ISO Code Grade Physical and mechanical properties Applications recommended
Grade Density g/cm3 Hardness No Less Than HRA(HV) TRS No Less Than (Mpa)
K05 YG3 15 90.5 1300 Suitable for finishing of cast iron and nonferrous metal.
K10 YG6X 14.8 91 1700 The finishing& semi-finishing of cast iron and nonferrous metals and also for the machining of manganese stell and hardening steel.
K15 YG6 14.9 89.5 1670 Suitable for the roughing of cast iron and light alloys and also for the milling of cast iron and low-alloy steel.
K20 K30 14.6 89 1840 Suitable for the roughing of cast iron and light alloys and also for the milling of cast iron and low-alloy steel.
M10 YW1 13 91 1290 Suitable for finishing and semi-finishing of stainless steel and conventional alloy steel
YW3 12.9 92 1390
YW4 12.3 92 1390
M20 YW2 13 90.5 1460 The grade can be used for the semi-finishing of stainless steel and low-alloy steel and it is mainly used for the maching of railway wheel hubs.
YL10.2 14.5 91 2800

It has a high flexural strength, and good wear resistance, the use of low-speed rough turning, milling and wear-resistant alloy titanium alloy.
