CNC Machines Tools Carbide Single Flute Spiral End Mill For Milling Cutter
CNC Machines Tools Carbide Single Flute Spiral End Mill For Milling Cutter
CNC Machines Tools Carbide Single Flute Spiral End Mill For Milling Cutter
CNC Machines Tools Carbide Single Flute Spiral End Mill For Milling Cutter
CNC Machines Tools Carbide Single Flute Spiral End Mill For Milling Cutter
CNC Machines Tools Carbide Single Flute Spiral End Mill For Milling Cutter
CNC Machines Tools Carbide Single Flute Spiral End Mill For Milling Cutter
CNC Machines Tools Carbide Single Flute Spiral End Mill For Milling Cutter
CNC Machines Tools Carbide Single Flute Spiral End Mill For Milling Cutter
CNC Machines Tools Carbide Single Flute Spiral End Mill For Milling Cutter
CNC Machines Tools Carbide Single Flute Spiral End Mill For Milling Cutter
CNC Machines Tools Carbide Single Flute Spiral End Mill For Milling Cutter
Specifications
Brand Name :
Jin Tai Pai
Model Number :
D1-D20 OEM service available
Certification :
SGS
Place of Origin :
China
MOQ :
Negotiable, sample order acceptable
Price :
Negotiable, depends on carbide grade and quantity.
Supply Ability :
20 Ton/Tons per Month
Delivery Time :
7-25 days, depends on order
Packaging Details :
Packed in plastic tube or as your requirments.
Payment Terms :
L/C, T/T, Western Union
Product Name :
CNC Machines Tools Carbide Single Flute Spiral End Mill For Milling Cutter
Material :
Carbide, tungsten carbide
Flute :
2/3/4
Spiral Angle :
30 degree
Machine Type :
Milling Machine
Usage :
Metalworking
Description

CNC Machines Tools Carbide Single Flute Spiral End Mill For Milling Cutter

Feature

1. Good Surface
2. High Precision
3. Good Performance
4. Certification: ISO9001:2008, Supplier Assessment Certificate

Specifications

HRC 60 solid carbide end mill

Blade diameter range from 0.5mm to 10 mm, spiral angle 30 degree, hardness HRC 60.

Fine tungsten carbide, WC=90%,CO=10%,TRC>3800N/㎡, ideal for carbon steel, alloy steel and iron mold materials.

HRC 60 square end mill

square carbide end mill

Type Blade diameter Blade length Shank diameter Total length
1.0x3x4Dx50L 1 3 4 50
1.5x4x4Dx50L 1.5 4 4 50
2.0x6x4Dx50L 2 6 4 50
2.5x8x4Dx50L 2.5 8 4 50
3.0x3x4Dx50L 3 8 4 50
3.5x10x4Dx50L 3.5 10 4 50
4.0x11x4Dx50L 4 11 4 50
3.0x8x6Dx50L 3 8 6 50
3.5x10x6Dx50L 3.5 10 6 50
4.0x11x6Dx50L 4 11 6 50
4.5x13x6Dx50L 4.5 13 6 50
5.0x13x6Dx50L 5 13 6 50
5.5x13x6Dx50L 5.5 13 6 50
6.0x15x6Dx50L 6 15 6 50
7.0x16x8Dx60L 7 16 8 60
8.0x20x8Dx60L 8 20 8 60
9x20x10Dx75L 9 20 10 75
10x25x10Dx75L 10 25 10 75
11x25x12Dx75L 11 25 12 75
12x30x12Dx75L 12 30 12 75
14x35x14Dx100L 14 35 14 100
16x40x16Dx100L 16 40 16 100
18x45x18Dx100L 18 40 18 100
20x45x20Dx100L 20 45 20 100

Square end mills of other blade diameter and length are possible as per customers’ requirement.

CNC Machines Tools Carbide Single Flute Spiral End Mill For Milling Cutter

Applications

1. Suitable for Copper, Cast Iron, Carbon steel, Tool steel, Mould steel, Die steel, Stainless steel, Plastic, Arcylic, etc.

2. Applicated for Aerospace, transportation, Medical equipment, military manufacturing, mould development, apparatus and instrument, etc

CNC Machines Tools Carbide Single Flute Spiral End Mill For Milling Cutter

CNC Machines Tools Carbide Single Flute Spiral End Mill For Milling Cutter
