Specifications
Brand Name :
JinTaiPai
Model Number :
Various or Customized dimension available
Certification :
SGS ISO certificated
Place of Origin :
Hunan, China
MOQ :
Negotiable, sample order acceptable
Price :
Negotiable, depends on carbide grade and quantity.
Supply Ability :
300 Ton/Tons per Month
Delivery Time :
7-25 days, depends on quantity.
Packaging Details :
Pack with shock resistance foam first in plastic box, and then carton boxes outside. Or pack according to your request
Payment Terms :
L/C, T/T, Western Union
Alloy Specification :
K01, K10, K20 carbide grade
Particle :
0.2-1.7um
Product name :
Un-ground and Finish-ground (metric diameters, h6 tolerance) Standard Carbide Rod
Material :
100% virgin carbide material
Surface :
High Polished, h6
Certificate :
ISO
Color :
Silver Gray
Application :
Machinery Tools
Hardness :
HRA 85-93
Description
End mills,reamers and gravers are recommended. Excellent performance for high speed cutting. Suitable for cutting hardened steel, aluminum alloy and Titanium alloy. We provide custom-made, near-net-shape, premium insert blanks in cemented carbide - also known as Tungsten carbide or solid carbide.

Carbide K10 K20 Tungsten Carbide Fixed Length Polished Rods 100% Virgin

Properties of cemented carbide grades recommended rods

Grade

Chemical composition

Physical data

Grain size of WC(um)

WC

Co

Others

Density(g/cm³)

Hardness(HV3)

TRS(MPa)

YL10.1

93.5%

6.0%

0.5%

14.88-15.04

1580±50

2500

1.2-1.7

YL10.2

89.5%

10.0%

0.5%

14.4-14.55

1600±50

4000

0.8

YL10.5

89.7%

9.5%

0.8%

14.4-14.55

1550±50

3800

0.7-0.9

YL50

85.0%

15.0%

13.86-14.10

1095

2060

0.4-0.6

YU06

93.0%

6.0%

1.0%

14.7-14.8

2050

3000

0.2-0.4

YU08

91.0%

8.0%

1.0%

14.56-14.65

1900

4000

0.2-0.4

YU09

89.8%

9.0%

1.2%

14.36-14.50

1950

3900

0.2-0.4

YU12

87.0%

12.0%

1.0%

14.05-14.15

1750

4000

0.2-0.4

YF06

93.5%

6.0%

0.5%

14.86-14.96

1800

3800

0.4-0.6

YF08

91.4%

8.0%

0.6%

14.55-14.65

1800

3900

0.4-0.6

YG6X

93.5%

6.0%

0.5%

14.8-15.10

91

1560

1.0

YG8

92.0%

8.0%

14.6-14.9

89.5

1840

1.2-1.6

~ Customized Tungsten carbide products are available!

Carbide K10 K20 Tungsten Carbide Fixed Length Polished Rods 100% Virgin

Type D(mm) Tol. Of diameter(mm) L(mm) Tol. Of diameter(mm)
￠1.0*330 1.0 +0.2~+0.45 330 0~+5.0
￠2.0*330 2.0 +0.2~+0.45 330 0~+5.0
￠3.0*330 3.0 +0.2~+0.45 330 0~+5.0
￠4.0*330 4.0 +0.2~+0.45 330 0~+5.0
￠5.0*330 5.0 +0.2~+0.45 330 0~+5.0
￠6.0*330 6.0 +0.2~+0.45 330 0~+5.0
￠7.0*330 7.0 +0.2~+0.45 330 0~+5.0
￠8.0*330 8.0 +0.2~+0.45 330 0~+5.0
￠9.0*330 9.0 +0.2~+0.45 330 0~+5.0
￠10.0*330 10.0 +0.2~+0.5 330 0~+5.0
￠11.0*330 11.0 +0.2~+0.5 330 0~+5.0
￠12.0*330 12.0 +0.2~+0.5 330 0~+5.0
￠13.0*330 13.0 +0.2~+0.5 330 0~+5.0
￠14.0*330 14.0 +0.2~+0.5 330 0~+5.0
￠15.0*330 15.0 +0.2~+0.6 330 0~+5.0
￠16.0*330 16.0 +0.2~+0.6 330 0~+5.0
￠17.0*330 17.0 +0.2~+0.6 330 0~+5.0
￠18.0*330 18.0 +0.2~+0.6 330 0~+5.0
￠19.0*330 19.0 +0.2~+0.6 330 0~+5.0
￠20.0*330 20.0 +0.2~+0.7 330 0~+5.0
￠21.0*330 21.0 +0.2~+0.7 330 0~+5.0
￠22.0*330 22.0 +0.2~+0.7 330 0~+5.0
￠23.0*330 23.0 +0.2~+0.7 330 0~+5.0
￠24.0*330 24.0 +0.2~+0.7 330 0~+5.0
￠25.0*330 25.0 +0.2~+0.7 330 0~+5.0
￠26.0*330 26.0 +0.2~+0.8 330 0~+5.0
￠27.0*330 27.0 +0.2~+0.8 330 0~+5.0
￠28.0*330 28.0 +0.2~+0.8 330 0~+5.0
￠29.0*330 29.0 +0.2~+0.8 330 0~+5.0
￠30.0*330 30.0 +0.2~+0.8 330 0~+5.0

Carbide K10 K20 Tungsten Carbide Fixed Length Polished Rods 100% Virgin
Carbide K10 K20 Tungsten Carbide Fixed Length Polished Rods 100% Virgin
Carbide K10 K20 Tungsten Carbide Fixed Length Polished Rods 100% VirginCarbide K10 K20 Tungsten Carbide Fixed Length Polished Rods 100% Virgin
