Backward Material Handling Blower Fan Medium Pressure Antifraying
Backward Material Handling Blower Fan Medium Pressure Antifraying
Backward Material Handling Blower Fan Medium Pressure Antifraying
Backward Material Handling Blower Fan Medium Pressure Antifraying
Backward Material Handling Blower Fan Medium Pressure Antifraying
Backward Material Handling Blower Fan Medium Pressure Antifraying
Specifications
Brand Name :
SIMO
Model Number :
SIMO Blower 5-10
Certification :
CE, ISO9001:2008,TUV
Place of Origin :
Henan China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
T/T, L/C, Payment Term Is Negotiable
Supply Ability :
500 Sets Per Month
Delivery Time :
15-35 Days
Packaging Details :
Export Wooden Case Packing, Steel pallet Packing
Material :
Carbon Steel/Alloy Steel/Stainless Steel
After-sales Service Provided :
Field installation, commissioning and training
Impeller test :
Ultrasonic flaw detection
Power source :
Three Phase AC Motor
Color :
Customer's Requirement
System Type :
Single inlet, Overhang type
Description

Medium Pressure Backward Antifraying Material Handling Blower Fan

Introduction

The 5-10 series ventilator is a high efficiency and energy saving product developed by our company, which is used for ventilation and exhaust system of smelting, chemical, medicine and dust removal production lines.

The impeller is subjected to a high standard of dynamic balancing adjusting to ensure stable operation of the fan.

Test assembly after production is completed to ensure that there is no interference between the components.

Provide on-site arrangement and guidance services.

Technical data

series model Rotation Speed
(r/min)		 Total Pressure
(Pa)		 Air Capacity
(m³/h)		 Power
(kW)
5-10 4C 2900 1606～1232 3007～5152 3
4.5C 2880 2004～1538 4252～7284 5.5
5C 2900 2509～1925 5873～10062 7.5
5.4C 2900 2927～2246 7398～12675 11
6C 2500 2685～2060 8749～14989 15
8C 2000 3055～2344 16591～28424 30
9C 2000 3867～2967 23623～40471 45
10C 1600 3055～2344 25923～44413 45


FAQ

1,Q: What’s the MOQ of your company?

A: The MOQ is 1set.

2,Q: How long is the delivery time?

A : A:5-35 days.

3,Q : What’s your payment terms?

A : T/T, L/C, or Negotiable.

4,Q: What’s your warranty?
A: 1 year.
5,Q: Is your company factory or trade company?

A: We have our own factory, our type is factory +trade.
