Carbon Steel Single Suction Backward Curved Material Handling Blower
Carbon Steel Single Suction Backward Curved Material Handling Blower
Carbon Steel Single Suction Backward Curved Material Handling Blower
Carbon Steel Single Suction Backward Curved Material Handling Blower
Carbon Steel Single Suction Backward Curved Material Handling Blower
Carbon Steel Single Suction Backward Curved Material Handling Blower
Specifications
Brand Name :
SIMO
Model Number :
SIMO Blower 5-12
Certification :
CE, ISO9001:2008,TUV
Place of Origin :
Henan China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
T/T, L/C, Payment Term Is Negotiable
Supply Ability :
500 Sets Per Month
Delivery Time :
15-35 Days
Packaging Details :
Export Wooden Case Packing, Steel pallet Packing
Material :
Carbon Steel/Alloy Steel
Voltage :
380V
Current Type :
AC
Power source :
Three Phase AC Motor
Warranty :
1 Year
Impeller Support :
SWSI (Single Width, Single Inlet), Impeller overhung
Description

Carbon Steel Single Suction Backward Curved Material Handling Blower

Introduction

The 5-12 series centrifugal fan is an enhanced version of the 5-11 series medium pressure centrifugal fan.

It has a larger output flow than the 5-11 series. It is also used to transport a variety of common gases and hard materials in the industrial field, the application object is exactly the same as 5-11 series fan.

In the case of a monolithic bracket, the installation is very simple and requires little support from a professional technician.

After the production is completed, all products are tested for running and vibration values for reliable operation.

Technical data

series model Rotation Speed
(r/min)		 Total Pressure
(Pa)		 Air Capacity
(m³/h)		 Power
(kW)
5-12 4D 2500～3550 742～2221 2065～5564 2.2～5.5
5D 2240～3150 964～2819 3772～9851 4～11
6.3D 2000～2800 1221～3545 6737～17516 7.5～22
8D 1400～2000 1100～3323 9656～25619 11～30
10D 1250～1800 1419～4483 15451～44634 22～75
12.5D 1000～1400 2145～4234 24143～67803 37～110

FAQ

1,Q: What’s the MOQ of your company?

A: The MOQ is 1set.

2,Q: How long is the delivery time?

A : A:5-35 days.

3,Q : What’s your payment terms?

A : T/T, L/C, or Negotiable.

4,Q: What’s your warranty?
A: 1 year.
5,Q: Is your company factory or trade company?

A: We have our own factory, our type is factory +trade.

Carbon Steel Single Suction Backward Curved Material Handling Blower

Carbon Steel Single Suction Backward Curved Material Handling Blower
