Mining Sludge Industrial Vertical Submerged Pump With Packing Seal 11 - 200kw
Mining Sludge Industrial Vertical Submerged Pump With Packing Seal 11 - 200kw
Mining Sludge Industrial Vertical Submerged Pump With Packing Seal 11 - 200kw
Mining Sludge Industrial Vertical Submerged Pump With Packing Seal 11 - 200kw
Specifications
Brand Name :
SHIZA
Model Number :
PN
Certification :
ISO CE
Place of Origin :
CHINA
MOQ :
1 set
Price :
based on quantity
Supply Ability :
300sets monthly
Packaging Details :
wooden case
Sealing :
Packing seal
keyword :
Effluent Handling Underflow Vertical Centrifugal Slurry Pump
Submerged slurry pump impeller: :
Semi-open impeller
structure :
Vertical type slurry pump
Application :
Mining
Description

Mining Sludge Industrial Vertical Sump Pumps With Packing Seal 11 - 200kw

1. PNL series sand pump is one kind of vertical dry sand unloading pump .

2. Made up of pump body,impeller,guard board,electricity frame,bearing assembly and so on.

3. Adopts advanced technology to design and manufacture,having long service life.

4. The equipment and operation is simple and easy.

5. Improved upon the basis of similar products by our company.

6.High efficiency and low cost.

7.Wear resistant wet parts which are made of hard metal (Chrome alloy).

8.Long bearing life: The bearing assembly is with large diameter shaft and short overhang

Applications

1. PNL sludge pumps used for delivering abrasive,particle and high- density slurries and applied over

the fields such as metallurgy, mining, coal, power, building materials, and environmental protection.

2. Applied in the coastal shoal farm’s excavation,river dredging,diking,transformation,sand extraction,the

basic construction of farmland and undergroundworks,etc.

Performance Table:

Model flow head speed NPSH efficiency power installed with power weight CAL dischang
1PN 7.2 14 1430 0.53 21 1.3 3 120 50 25
12 13 30 1.41
16 12 35 1.5
2PN 30 22 1450 1.32 33 5.45 11 150 96 50
47 19 39 6.25
58 17 39 6.9
2PNL 30 22 1450 1.32 33 5.45 11 250 62 53
47 19 39 6.25
58 17 39 6.9
3PNL 54 26 1470 2.35 32 12 22 450 125 75
108 21 42 14.7
151 15 37 16.7
3PN 54 26 1470 2.35 32 12 22 280 90 85
108 21 42 14.7
151 15 37 16.7
4PN 100 41 1470 2.95 46 24.3 55 1000 150 100
150 39 55 29
200 37 61 33.1
4PN(1) 41.5 51 1470 1.92 23 25 55 1000 150 100
80 50 36 30.2
111 49 44.5 33.1
4PN(2) 52 51 1470 2.2 26 28 75 1000 150 100
100 50 37 37
138 49 47 39
6PN 230 27 980 2.59 56 30.2 75 2.59 200
280 26 60 33
320 25 62 35.2

Mining Sludge Industrial Vertical Submerged Pump With Packing Seal 11 - 200kw
