Electric Motors Metal Lined Slurry Pumps Horizontal S45C 62HRC
Electric Motors Metal Lined Slurry Pumps Horizontal S45C 62HRC
Electric Motors Metal Lined Slurry Pumps Horizontal S45C 62HRC
Electric Motors Metal Lined Slurry Pumps Horizontal S45C 62HRC
Electric Motors Metal Lined Slurry Pumps Horizontal S45C 62HRC
Electric Motors Metal Lined Slurry Pumps Horizontal S45C 62HRC
Specifications
Brand Name :
CNSME
Model Number :
6/4D-
Certification :
ISO/CE
Place of Origin :
CHINA
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
100 Sets per Month
Delivery Time :
7 -20 Working Days
Packaging Details :
Plywood Crate
Material :
High Chrome Alloy A05
Shaft :
Horizontal S45C
Lubrication :
Grease
Name :
Metal Lined Slurry Pumps
Approval :
ISO/CE
Driven :
Electric Motors
Description

6 / 4 D Metal Lined Slurry Pumps driven by Electric Motors through Belts and Pulleys

Introduction:

Advantages and Uses of Series ‘A’ Type '' Slurry Pumps:
Designed for the continuous pumping of highly abrasive and/or corrosive slurries. These pumps feature a wide choice of replaceable hard metal or pressure moulded elastomer liners and impellers and are all interchangeable within the same casing.
The centrifugal shaft seal is commonly used, but an interchangeable packed gland seal is also available for every pump. Special mechanical seals for slurry service are being developed.
Ease of maintenance features include:
• Through bolt design
• Minimum number of casing bolts
• Slip fit replaceable Shaft sleeve
• Cartridge type Bearing Assembly
• Cast in Impeller thread
• Replaceable liners are positively attached
• Impeller Release Collar on large models
Centrifugal Sealing - Lubrication
In centrifugally sealed pumps, lubricate the static seal chamber sparingly but regularly, by means of the grease cup.
The grease for the centrifugally sealed pump static seal chamber should have the following specifications:
A lithium complex soap thickener grease with EP additives and oxidation inhibitors.
N.L.G.I. Consistency No 2
Drop Point  260 °C
Work penetration 25°C A.S.T.M. 265 - 295
RECOMMENDED GREASE: MOBIL HP or equivalent.

Typical Applications:

Ash Handling

Minerals Processing

Cyclone Feeds

Pulp and Paper

Abrasive Slurries

Coal Preparation

Mineral Processing

Aggregate Processing

Sugar Cane

Material: High Chrome Alloy A05

Material Chemical Requirements, Weight%

Description Material Name C Mn Si Ni Cr Mo Cu P V S Description Hardness
A05 Ultrachrome 2.92 0.98 0.54 0.8 27 ≤0.8 ... 0.062 ... 0.051 27% Cr Erosion Resistant White Iron 58-62HRC

Construction of SH Slurry Pumps:

Electric Motors Metal Lined Slurry Pumps Horizontal S45C 62HRC

Performance Curve:

6/4D- Slurry Pump

Electric Motors Metal Lined Slurry Pumps Horizontal S45C 62HRC

Exploded Drawing:

Electric Motors Metal Lined Slurry Pumps Horizontal S45C 62HRC

General Assembly Drawing:

Electric Motors Metal Lined Slurry Pumps Horizontal S45C 62HRC
