Longer Wear Life Type Heavy Duty Slurry Pump with Over 100 Years Operation Experience
Longer Wear Life Type Heavy Duty Slurry Pump with Over 100 Years Operation Experience
Longer Wear Life Type Heavy Duty Slurry Pump with Over 100 Years Operation Experience
Longer Wear Life Type Heavy Duty Slurry Pump with Over 100 Years Operation Experience
Longer Wear Life Type Heavy Duty Slurry Pump with Over 100 Years Operation Experience
Longer Wear Life Type Heavy Duty Slurry Pump with Over 100 Years Operation Experience
Specifications
Brand Name :
CNSME
Model Number :
10/8F-
Certification :
ISO/CE
Place of Origin :
CHINA
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
20 Sets per Month
Delivery Time :
15 Working Days
Packaging Details :
Plywood Crate
Flowrate :
612-1368m3/h
Head :
11-61m
Speed :
400-850r/min
Efficiency :
Max. 71%
Impeller :
5-Vane Enclosed Type
Solids :
Up to 76mm
Description

Longer Wear Life Type Slurry Pump with Over 100 Years Operation Experience

Introduction:

1. Compared with other brands of slurry pumps that are serving the market, Our type heavy duty slurry pumps can offer:

＞Higher performance;

＞Longer wear life;

＞Less power consumption;

＞Less maintenance.

2. 10/8F- is one of the best seller pump model in SME with 10 inches suction and 8 inches discharge, the capacity can be 1368m/h and rated motor power can be 260kw, which can by driven by elec. motor or diesel engine by either couplings or V-belts.

3. The material of the wet-end parts, including impeller, volute liner, front and back liner, expeller and expeller ring, are made of high chrome alloy A05, of which the rockwell hardness can reach a max. of 68HRC.

Specifications:

Model SH-200F
Oulet 8-inch
Capacity 612-1368m3/h
TDH 11-61m
Rated Motor Power 260Kw
Speed 400-850r/min
NPSH 4-10m

Construction of SH Slurry Pumps:

Longer Wear Life Type Heavy Duty Slurry Pump with Over 100 Years Operation Experience

Standard Material of Wet-end Parts: Hi-Chrome Alloy A05

Designation Description C Mn Si Ni Cr Mo P S V Hardness
A05 27% Cr White Iron 2.92 0.98 0.54 0.8 26-28 ≤0.8 0.062 0.05 0 58-62HRC

Typical Applications:

Ash Handling

Cyclone Feeds

Pulp and Paper

Abrasive Slurries

Coal Preparation

Mineral Processing

Aggregate Processing

Used in quarries
