Specifications

Brand Name :

Antaeus

Model Number :

AD-I002

Certification :

Place of Origin :

Hunan,China

MOQ :

Negotiation

Price :

Negotiation

Payment Terms :

T/T or Negotiation

Supply Ability :

Full Supply

Delivery Time :

15-45 days

Packaging Details :

Inner vacuum packaging, outside carton.

Chemical ingredients :

Al2O3

Max. Use Temp. :

1650℃

Bulk Density :

3.6g/cm3-3.9g/cm3

Water absorption :

ROHS Hardness :

≥85

Flexural strength :

358(52) - 550 Mpa(psix10^3)

Compressive Strength :

2068(300) - 2600(377) Mpa(psix10^3)

Coefficient of thermal expansion :

7.6 - 8.2 / 1X10^-6/℃

Coefficient of thermal conductivity :

16-30.4 / W/m.K

Thermal Shock Resistance :

250℃

Dielectricity constant :

9-9.7 / 1MHz.25℃

Dielectric strength :

8.3(210) - 8.7(220) / ac-kV/mm(ac V/mil)

Volume Resistivity :

>10^13 ohm-cm

Description

Alumina Ceramic Insulator /Electrical Insulation Rod For Oxygen Sensor

1. Description:

These mullite tubes can repeatedly be exposed to temperature fluctuations without deforming or cracking. They can be used as a protective cover over materials that are moved between hot and cold environments, such as thermocouples. These tubes are fully fired and seal out air and gas in high temperature applications like nonporous alumina. They also resist corrosion from a variety of chemicals. Use them in furnaces, heaters, electrical insulation, and glass- and steel-industry refractories.

2. Feature Advantages:

1) Abrasion resistance

2) Impact resistance

3) High precision

4) High stability

5) High welding sealing performance

6) Good wear resistance

3. Material Features / Properties:

Composite	(wt %)	99%	99.5%	99.8%
Color		White or Ivory	White or Ivory	White or Ivory
Density	g/cm 3	3.82	3.9	3.92
Hardness	HRA	83	85	85
Flexural Strength	Mpa (psi*10 3 )	375	386	381

4. Technical Parameters:

Technical Parameters of Ceramics
Items	Test Conditions	Unit or Symbol	99% AL2O3	95% AL2O3	90% AL2O3	Zirconia	Steatite	Silicon Carbide
Volume Density	--	g/cm3	≥3.70	≥3.62	≥3.40	≥5.90	≥2.60	≥3.08
Tightness	--	Pa·m³/s	≤1.0×10-11	≤1.0×10-11	≤1.0×10-11	-	-	-
Liquid Permeability	--	--	Pass	Pass	Pass		Pass	-
Flexural Strength	-	MPa	≥300	≥280	≥230	≥1100	≥120	≥400
Elastic Modulus	-	GPa	-	≥280	≥250	≥220	-	400
Poisson Ratio	-	-	-	0.20～0.25	0.20～0.25	-	-	-
Thermal Shock Resistance	800℃( Room Temperature) Cycle: 10 times		Pass	Pass	Pass	-	-	-
Coefficient of Linear Expansion	20℃～100℃	×10-6 K-1	-	-	-		≤8	-
	20℃～500℃	×10-6 K-1	6.5～7.5	6.5～7.5	6.5～7.5	6.5～11.2	-	-
	20℃～800℃	×10-6 K-1	6.5～8.0	6.5～8.0	6.3～7.3		-	4
	20℃～1200℃	×10-6 K-1	-	7.0～8.5	-	-	-	-
Coefficient of Thermal Conductivity	20℃	W/(m·k)	-	-	-	-	-	90～110
Coefficient of Thermal Conductivity	1000℃	W/(m·k)	-	-	-	-	-	90～110
Dielectric Constant	1MHz 20℃	-	9.0～10.5	9.0～10	9.0～10	-	≤7.5	-
	1MHz 50℃	-	-	9.0～10	-	-	-	-
	10GHz 20℃	-	9.0～10.5	9.0～10	9.0～10	-	-	-
Volume Resistivity	100℃	Ω·cm	≥1.0×1013	≥1.0×1013	≥1.0×1013	-	≥1.0×1012	-
	300℃		≥1.0×1013	≥1.0×1010	≥1.0×1013	-	-	-
	500℃		≥1.0×109	≥1.0×108	--	-	-	-
Disruptive Strength	D.C	kV/mm	≥17	≥15	≥15	-	≥20	-
Chemical Durability	1:9HCl	mg/c㎡	≤0.7	≤7.0	-	-	-	-
Chemical Durability	10%NaOH	mg/c㎡	≤0.1	≤0.2	-	--	-	-
Grain Size	-	μm	-	3~12	-	-	-	-

5. Process Flows:

Formulating --- Granulating --- Forming --- Sintering --- Grinding --- Inspecting --- Packing
