Zirconia Turbine Suitable For Use Under High Speed, Ultra-High Temperature And Ultra-Humid Conditions
Zirconia Turbine Suitable For Use Under High Speed, Ultra-High Temperature And Ultra-Humid Conditions
Zirconia Turbine Suitable For Use Under High Speed, Ultra-High Temperature And Ultra-Humid Conditions
Zirconia Turbine Suitable For Use Under High Speed, Ultra-High Temperature And Ultra-Humid Conditions
Zirconia Turbine Suitable For Use Under High Speed, Ultra-High Temperature And Ultra-Humid Conditions
Zirconia Turbine Suitable For Use Under High Speed, Ultra-High Temperature And Ultra-Humid Conditions
Specifications
Place of Origin :
China
Brand Name :
Cersol
Certification :
MSDS, TDS
MOQ :
20KG
Packaging Details :
BARRELS, CARTONS
Delivery Time :
USUALLY 1 MONTH
Payment Terms :
T/T IN ADVANCE
Supply Ability :
80,000KG
Model Number :
C-BN-E10
color :
white
structure :
liquid
material :
boron nitride
Description

The one-piece all-ceramic grading wheel manufactured by cold isostatic pressing can effectively avoid wear and tear and isolate metal contamination. It can also extend the service life of the grading wheel and reduce the number of maintenance times, thereby saving costs and ensuring material quality.

Zirconia Turbine Suitable For Use Under High Speed, Ultra-High Temperature And Ultra-Humid Conditions

Technical Data

Material ZrO2

Fracture toughness

MPa・m1/2

 8

Elastic Modulus

(Gpa)

 200
Hardness (HV) 1350 Color White Poisson's Ratio 0.3
Thermal Expansion Coefficient (10-6/°C) 10 water absorption(%) < 0.01 Ingredient content (%) ZrO₂≤95
Firing temperature 1550-2600 Compressive strength(Mpa) 2000

Dielectric constant

(1MHZ)

 28
Temperature resistant (°C) 1800 Hardness(Hra) 88

mirror reflection

(Ra)

 ≤0.05
Specific Gravity (g/cm³) 6.01

Volume resistance

(cm)

 > 1012

Thermal conductivity

(W/m.K)

 5
Flexural Strength (MPa) 800-1000

Roughness

(µm)

 ≤ 0.8

Thermal shock resistance

(△T.℃)

 400

Features

●High hardness, high toughness, high flexural strength

●High wear resistance, low friction coefficient

●Strong corrosion resistance
●Good insulation, no static electricity

●High temperature resistance, excellent heat insulation performance
●Self-lubricating, which can solve the pollution and inconvenience caused by lubricating media.

Precision Machining

1. 3Y, 5Y, 8Ymol yttrium stabilized zirconium oxide powder
2. Mold opening processing: dry molding, CIM injection molding, isostatic pressing molding.
3. Appearance processing: surface grinding, outer diameter/inner diameter grinding, engraving machining, grinding, polishing and grinding.

Zirconia Turbine Suitable For Use Under High Speed, Ultra-High Temperature And Ultra-Humid Conditions

Zirconia Turbine Suitable For Use Under High Speed, Ultra-High Temperature And Ultra-Humid Conditions
