Specifications
Brand Name :
Zhengtong
Model Number :
B20-B505
Place of Origin :
Zhengzhou
MOQ :
100KGS
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
200mts per month
Delivery Time :
3-5 days after order confirmed
Packaging Details :
2*12.5kg barrel+ carton box + pallet or 25kg barrel+pallet
Commodity :
Ceramic Blasting Beads
Product Name :
Ceramic Blasting Media
Usage :
Surface finish for 3C products
Bulk Density :
2.3 g/cm3
True Gravity :
3.85 g/cm3
Vicker Hardness :
700HV
Main Material :
60-66% ZrO2
Package :
25kgs bucket+Pallet
Certification :
N/A
Description

10L, 12L barrels packed 25kgs Ceramic media blasting beads B120 size 63-125 μm

DESCRIPTION

Ceramic beads is a kind of dust free sandblasting media. It’s manufactured by electric fusion at high temperatures more than 2000℃ in ore furnace, with main raw materials of Zirconia sands. Production process including smelting-flow into micro beads-screen- air cleaning and fine screen to different sizes from B20 to B505, and Z100-Z850.

The features of ceramic beads are spherical shape and good elasticity, suitable for complex workpieces. It is also of no metal pollution and dust free.

Applicable for sandblasting and forming of

  • Steel;
  • Stainless steel;
  • Titanium alloy;
  • Aluminum alloy;
  • High temperature alloy
  • Copper
  • and other metals;

The ceramic beads is used for surface treatments like sandblast cleaning, deburring, pretreatment before coating and precise surface treatment .

It has concentrated grain sizes to obtain uniformity.

Technical Data
Components Content CAS No. EC No.
ZrO2 (Zirconium dioxide) 60-68% 1314-23-4 215-227-2
SiO2 (Silicon dioxide) 25-30 60676-86-0 262-373-8
Al2O3 (Aluminum oxide ) 7-13% 1344-28-1 215-691-6
Manufacturing Method Melting in above 2000℃ furnace
True Density 3.85 g/cm3
Bulk Density 2.3g/cm3
Vicker Hardness 700HV
Sizes for Sand Blasting
Bead Size Size range Bead Size Size range
B20 0.60-0.85 mm B120 0.063-0.125 mm
B30 0.425-0.60 mm B125 0.000-0.125 mm
B40 0.24-0.425 mm B170 0.045-0.090 mm
B60 0.125-0.25 mm B205 0.000-0.063 mm
B80 0.18-0.25 mm B400 0.030-0.063 mm
B100 0.125-0.18 mm B505 0.000-0.030 mm
Sizes for Shot Peening
Z850 0.85-1.18 mm Z210 0.21-0.30 mm
Z600 0.6-0.85 mm Z150 0.15-0.21 mm
Z425 0.425-0.60 mm Z100 0.10-0.15 mm
Z300 0.30-0.425 mm 　 　

FEATURES

  • High impact resistance and round beads, not easy to be broken. The broken rate of ceramic beads is around 1%.
  • Low dust generation, friendly to the environment and worker’s health.
  • Matte Metallic luster, no polishing reflective.
  • No metal pollution.

APPLICATION

  • · Sandblast cleaning for metal tools
  • · Descaling and deburring
  • · Alu alloy and Stainless steel surface satin finishing
  • · Painting/ coating stripping and pre treatment before coating

The ceramic beads is applicable to use in the mobile open sandblasting machine.

10L 12Lbarrels package 700HV 25kgs 125ΜM JZB120 Ceramic Bead Blasting

10L 12Lbarrels package 700HV 25kgs 125ΜM JZB120 Ceramic Bead Blasting

CONTACT US

Other main sandblasting abrasive available

01. Ceramic Beads

02. Glass Beads

03. Steel Shot

04. Brown fused alumina

05. White fused alumina

06. Black fused alumina

We can provide MSDS, COA, CERTIFICATE OF ORIGIN, etc.

Contact us to get more details about ceramic beads and other sandblasting media, you can get very fast response and professional service.
