25mm Thickness Ceramic Fiber Blanket 96kg/m3-160kg/m3 Density 1360 ℃
25mm Thickness Ceramic Fiber Blanket 96kg/m3-160kg/m3 Density 1360 ℃
25mm Thickness Ceramic Fiber Blanket 96kg/m3-160kg/m3 Density 1360 ℃
25mm Thickness Ceramic Fiber Blanket 96kg/m3-160kg/m3 Density 1360 ℃
Specifications
Brand Name :
FS
Model Number :
FS-7639
Certification :
SGS,CE
Place of Origin :
China
MOQ :
MOQ: 10PCS
Price :
11.7USD/roll
Payment Terms :
D/P, T/T, L/C, D/A, Western Union, MoneyGram
Supply Ability :
10000 roll/month
Delivery Time :
15 working days
Packaging Details :
Carton, PE
Working temperature :
1360 ℃
Chemical composition :
AL2O3+SIO2
Color :
white
Density :
96kg/m3-160kg/m3
Size :
customized
Fiber diameter :
3-5um
Application :
liners of industrial furnace
Al2O3+SiO2 :
96%
Feature :
Excellent heat insulation, fire prevention, sound absorption
Description

25mm Thickness Ceramic Fiber Blanket 96kg/m3-160kg/m3 Density 1360 ℃

Product Description

All kinds of aluminosilicate fiber blankets are made of ordinary type, standard type, high purity type, high aluminum type and zirconium type silicate fiber cotton by the process of silk forming.All kinds of needled blankets have the same excellent properties as the corresponding varieties of loose aluminosilicate fiber cotton, and have excellent kang tensile strength.The needle - punched carpet has even texture and smooth surface.

Needled blankets of different capacities and thicknesses provide a wide range of materials for users to obtain the best insulation structure and energy saving benefits.

Zirconium containing type, high aluminum silicate type aluminum fiber cotton;Through the high purity alumina silica powder synthesis material as raw materials, through the resistance furnace melting, blowing or throwing silk into fiber production process.

Application:

1. Industrial building materials kiln, heating device, high temperature pipe lining

2. Heat insulation for electric boilers, gas turbines and nuclear power plants

3, chemical industry high temperature reaction equipment and heating equipment wall lining

4, high temperature building fire prevention, heat insulation

5, furnace door, roof heat insulation

6. High temperature filter material

Features

Low thermal conductivity and low thermal capacity;Excellent thermal

Qualitative and thermal seismic resistance;Excellent tensile strength;

Excellent heat insulation, fire prevention, sound absorption.

25mm Thickness Ceramic Fiber Blanket 96kg/m3-160kg/m3 Density 1360 ℃

Product Parameters
Items Common Standard High pure High aluminium Contain zirconium
Classfication tem.(℃) 1260 1260 1300 1400 1430
Working tem.(℃) <1000 1000 1150 1260 1350
Color white pure white pure white pure white pure white
Chemical compostion(%) Al2O3 44-45 46 47-49 52-55 39-40
Al2O3+SiO2 96 97 99 99 --
Al2O3+SiO2+ZrO2 -- -- -- -- 99
ZrO2 -- -- -- -- 15-17
Fe2O3 <1.2 <1 0.2 0.2 0.2
Na2O+K2O ≤0.5 ≤0.5 0.2 0.2 0.2
Volume density (kg/m3) 96 128 96 128 96 128 96 128 96 128
Permanent linear contraction (%) -3 -3 -3 -3 -3
Insulation 24hours, (volume density 128kg/m3) 1000℃ 1000℃ 1100℃ 1200℃ 1350℃
Thermal conductivity at various surface temperatures(w/m.k) (volume density 128kg/m3)

0.09 (400℃)

0.16 (800℃)

0.09

(400℃)

0.16(800℃)

0.09(400℃)

0.16(800℃)

0.12

(600℃)

0.2

(1000℃)

0.16

(800℃)

0.2

(1000℃)
Tensile strength(Mpa) (volume density 128kg/m3) 0.04 0.04 0.04 0.04 0.04
Measure (mm) Common measure:3600*610*50 7200*610*20
