FS-4653 Ceramic Insulation Blanket 3-5um Fiber Diameter CE Certification
FS-4653 Ceramic Insulation Blanket 3-5um Fiber Diameter CE Certification
FS-4653 Ceramic Insulation Blanket 3-5um Fiber Diameter CE Certification
FS-4653 Ceramic Insulation Blanket 3-5um Fiber Diameter CE Certification
Specifications
Brand Name :
FS
Model Number :
FS-4653
Certification :
SGS,CE
Place of Origin :
China
MOQ :
MOQ: 10PCS
Price :
11.7USD/roll
Payment Terms :
D/P, T/T, L/C, D/A, Western Union, MoneyGram
Supply Ability :
10000 roll/month
Delivery Time :
15 working days
Packaging Details :
Carton, PE
Working temperature :
1430 ℃
Chemical composition :
AL2O3+SIO2
Color :
white
Density :
128kg/m3-160kg/m3
Size :
customized
Fiber diameter :
3-5um
Application :
furnace door, top cover heat insulation
Permanent linear contraction (%) :
-3
Description

FS-4653 Ceramic Insulation Blanket 3-5um Fiber Diameter CE Certification

Product Description

Ceramic fiber blanket is produced in a continuous way. After needling, the fibers are interwoven evenly, with high tensile strength and without any binding agent. Different bulk density and thickness of the needle blanket provides users with a wide range of materials, the company to provide customers a new type of refractory and heat insulation material, the product color white, size regular, set fire-resistant, heat insulation, heat preservation function into an organic whole, ceramic fiber blanket when used under neutral, oxidizing atmosphere can maintain good tensile strength, toughness and fiber structure, not affected by the oil, after drying can restore its thermal and physical properties.

FS-4653 Ceramic Insulation Blanket 3-5um Fiber Diameter CE Certification

Performance advantag

1. Low heat storage and low thermal conductivity
2. Excellent chemical stability
3. Excellent thermal stabilityc
4. Excellent tensile strength
5 No bonding agent and corrosive material

Application

1, industrial building materials kiln, heating device, high temperature pipe wall lining

2. Heat insulation for electric boilers, gas turbines and nuclear power plants

3, chemical industry high temperature reaction equipment and heating equipment wall lining

4, high-rise building fire prevention, heat insulation

5, furnace door, top cover heat insulation

Product Parameters
Items Common Standard High pure High aluminium Contain zirconium
Classfication tem.(℃) 1260 1260 1300 1400 1430
Working tem.(℃) <1000 1000 1150 1260 1350
Color white pure white pure white pure white pure white
Chemical compostion(%) Al2O3 44-45 46 47-49 52-55 39-40
Al2O3+SiO2 96 97 99 99 --
Al2O3+SiO2+ZrO2 -- -- -- -- 99
ZrO2 -- -- -- -- 15-17
Fe2O3 <1.2 <1 0.2 0.2 0.2
Na2O+K2O ≤0.5 ≤0.5 0.2 0.2 0.2
Volume density (kg/m3) 96 128 96 128 96 128 96 128 96 128
Permanent linear contraction (%) -3 -3 -3 -3 -3
Insulation 24hours, (volume density 128kg/m3) 1000℃ 1000℃ 1100℃ 1200℃ 1350℃
Thermal conductivity at various surface temperatures(w/m.k) (volume density 128kg/m3)

0.09 (400℃)

0.16 (800℃)

0.09

(400℃)

0.16(800℃)

0.09(400℃)

0.16(800℃)

0.12

(600℃)

0.2

(1000℃)

0.16

(800℃)

0.2

(1000℃)
Tensile strength(Mpa) (volume density 128kg/m3) 0.04 0.04 0.04 0.04 0.04
Measure (mm) Common measure:3600*610*50 7200*610*20
