1260℃ Thermal Insulation Material Ceramic Fiber Blanket For Furnace
1260℃ Thermal Insulation Material Ceramic Fiber Blanket For Furnace
1260℃ Thermal Insulation Material Ceramic Fiber Blanket For Furnace
1260℃ Thermal Insulation Material Ceramic Fiber Blanket For Furnace
Specifications
Brand Name :
FS
Model Number :
FS-9753
Certification :
SGS,CE
Place of Origin :
China
MOQ :
MOQ: 10PCS
Price :
11.7USD/roll
Payment Terms :
D/P, T/T, L/C, D/A, Western Union, MoneyGram
Supply Ability :
10000 roll/month
Delivery Time :
15 working days
Packaging Details :
Carton, PE
Working temperature :
1260 ℃
Chemical composition :
AL2O3+SIO2+Na2O+K2O
Color :
white
Density :
96kg/m3-160kg/m3
Size :
7200*610*10-50 mm
Fiber diameter :
3-5um
Application :
thermal insulation for electric boilers, gas turbines and nuclear power plants
Feature :
Thermal shock resistance
strength of extension(MPa) :
0.08-0.12
Permanent liner change(%) :
-3
Description

1260℃ Thermal Insulation Material Ceramic Fiber Blanket For Furnace

Product Description

The service temperature of Ceramic fiber blanket can be 1100℃,1260℃,1360℃,1430℃. It includes: common type, standard type, high purity type, high alumina type, zirconium containing type.

Low thermal conductivity, low heat storage

Good heat and chemical stability

Thermal shock resistance

Tensile strength

Good thermal insulation

Noise reduction

Fire proof

1260℃ Thermal Insulation Material Ceramic Fiber Blanket For Furnace

Applications

Industrial building materials kiln, heating device, high temperature pipe lining; chemical industry high temperature reaction equipment and heating equipment wall lining; thermal insulation for electric boilers, gas turbines and nuclear power plants; fire insulation layer for high-rise buildings; furnace door, roof heat insulation; high temperature filter material and so on.

Specifications

Ceramic fiber blanket Common type Standard type High purity type High alumina type Zirconium containing type
Classification temperature(℃) 1100 1260 1260 1360 1430
Service temperature(℃) <1000 1050 1100 1200 1350
Color White White White White White
Bulk density(kg/m3) 96 128 96 128 96 128 128 160 128 160

Permanent liner change(%)

(After 24 hours)(Bulk density 128kg/m3)

-4

(1000℃)

-3

(1000℃)

-3

(1100℃)

-3

(1250℃)

-3

(1350℃)

Thermal conductivity under each section(w/m·k)

(Bulk density 128kg/m3)

0.09(400℃)

0.176(800℃)

0.09(400℃)

0.176(800℃)

0.09(400℃)

0.176(800℃)

0.22(1000℃)

0.132(600℃)

0.22(1000℃)

0.76(800℃)

0.20(1000℃)

strength of extension(MPa)

(Bulk density 128kg/m3)

 0.08-0.12 0.08-0.12 0.08-0.12 0.08-0.12 0.08-0.12
Chemical content(%) Al2O3 44 46 47-49 52-55 39-40
Al2O3+SiO2 96 97 99 99 -
Al2O3+SiO2+ZrO2 - - - - 99
ZrO2 - - - - 15-17
Fe2O3 <1.2 <1.0 0.2 0.2 0.2
Na2O+K2O ≤0.5 ≤0.5 0.2 0.2 0.2
Size(mm) Standard size: 7200*610*10-50;Customized sizes are also avaliable
