Specifications
Place of Origin :
Zibo, Shandong
Brand Name :
HUAO
Certification :
ISO9001 ISO14001 ISO45001
Model Number :
OEM
Hardness :
9
Alumina Content :
92%,95%
Applications :
Steel industry, power industry ceramics, mines and lining of other grinding equipment.
Application :
All types machines with high wear resistance damaged.
Description

Alumina Ceramic Tiles

Introduction

The alumina ceramic tile is a special corundum ceramic made of AL2O3 as the main raw material and rare metal oxide as the flux, which is calcined at a high temperature of 1700 Baidu. Its Rockwell hardness is HRA80-90, and its hardness is second only to diamond. The performance is equivalent to 266 times that of manganese steel and 171.5 times that of high-chromium cast iron, so it can greatly extend the service life of pulverized coal pipe elbows.

Advantages

Alumina ceramic tile has the characteristics of wear-resisting, corrosion resistance, high temperature resistance, impact resistance and convenient construction. It is an ideal wear resistant material for conveying equipment in electric power, metallurgy, coal, petroleum, cement, chemical industry, machinery and other industries. Arc alumina wear resisting ceramic is used, which is very safe and reliable under high temperature corrosion, high temperature wear or high temperature melting, and has long service life. Under the same industrial and mining conditions, its service life is 10 to 20 times of casting stone, wear resistant alloy cast steel, steel rubber and other materials.

Application

Applications & Hardware
Application Fastening Methods Backing plates
raw meterial feed rubber bond plain rubber with captive studs
head chute liner studs mild steel
impact curtains captive socket 3 Cr 12
chute liner plug weld Stainless steel
rock boxes
skirt boards
bucket liner

Selling point

It has advantages of various types, high hardness(Rockwell hardness is HRA80-90), excellent wear resistance.

impact resistance, corrosion resistance, good heat resistance and light weightIt can save

the maintain cost,extend the life of machines

Technical Data

Item/Product

HA 92

HA95

ZTA

Al2O3(%)

92±0.5

95±0.5

76±0.5

ZrO2(%)

Bending Strendth(Mpa)

＞220

＞280

＞400

(Mpam1/2)Fracture Toughness

＞3.60

＞3.90

＞4.50

Rockwell Hardness (HPV)

＞82

＞88

＞90

Wear Volume(cm³)

＜0.50

＜0.30

＜0.15
