Smart Supply Snack Food Candy Bar Production Machine With CE ISO Passed
Smart Supply Snack Food Candy Bar Production Machine With CE ISO Passed
Smart Supply Snack Food Candy Bar Production Machine With CE ISO Passed
Smart Supply Snack Food Candy Bar Production Machine With CE ISO Passed
Smart Supply Snack Food Candy Bar Production Machine With CE ISO Passed
Smart Supply Snack Food Candy Bar Production Machine With CE ISO Passed
Specifications
Brand Name :
SMART
Model Number :
SRC-75
Certification :
CE ISO
Place of Origin :
China
MOQ :
1 set
Price :
negotiable
Payment Terms :
L/C, T/T
Supply Ability :
100 sets/month
Delivery Time :
35-45 working days
Packaging Details :
standard export case
Product Name :
Snack Food Candy Bar Production Machine
Capacity :
400-500kg/h
Voltage :
220/380v
Cooling type :
Cooling type
Weight :
1500kg
Dimension :
7500x1400x1300mm
Description

Snack Food Candy Bar Production Machine:

Introduction:

cereal bar making machine is applied to the production of varies kinds of cereal bar, such as peanut bar, nougat, and cereal bar with sesame, popcorn, dried fruit, expanded rice, oat, cereals etc.

The working principles of this line is the automatic or semi-automatic production of the full combination between teh warm keeping, forming and pressing rollers and the slitting technology;

Process Line:

Raw Material Mixing & Massing — Forming — Enrobing — Cooling — Packing

Raw Material:Rice crispy, nuts, dried fruit, chocolate, oat, cereals etc.

Technical parameter:

Modle SRC-75
Capacity 200-300kg/hr
Power 4kw
Dimension 12x4x2m
Workers Needed 3-4

Production flow of cereal bar machine:

The machine equips can be choosed by customer, and we can also supply chocolate coating machine.

DR-200 sugar boiler

is used to melt the sugar.

Double-layer design.
Heat evenly, and transferred by heat transfer oil.
The pot can be turned in 180 degree, which is easy to pour the sugar.
Equipped with mixing blades.
It has the function of warm-keeping.
1100 x 1100 x 900mm		 Smart Supply Snack Food Candy Bar Production Machine With CE ISO Passed
SRCT-35 Mixer is used to evenly mix the sugar with the puffed rice, millet, wheat, highland barley, fagopyrum tataricm Gaertn, maize, broomcorn, Chinese pearl barley, buckwheat, etc.
The hopper has warm-keeping function.
The coating has non-sticky design.
It has heating function, up to 120℃ (normally we suggest 80℃ to prevent over-cook the sugar).		 Smart Supply Snack Food Candy Bar Production Machine With CE ISO Passed
DRTS-20 Elevator This is used to convey the mixed material from mixer to the hopper of cereal bar cutting machine Smart Supply Snack Food Candy Bar Production Machine With CE ISO Passed
SRC-75 Cereal Bar Cutting Machine SRC-75 Cereal Bar Cutting Machine can be used for producing all kinds of cereal bars and sticks.

The SRC-75 Cereal bar cutting machine added mixer machine above the feeder. The machine come true the automatic mixing the raw material and pour the raw material to feeder. Mixer machine have the heat preservation function and could set the mixer time.		 Smart Supply Snack Food Candy Bar Production Machine With CE ISO Passed
LSU-220 Pillow Packing Machine is used for packing regular shape products, such as instant noodle, biscuit, wafer, moon cake, snow cake, etc. Smart Supply Snack Food Candy Bar Production Machine With CE ISO Passed

Cutting & Forming Machine

This machine are suitable for flatting and cutting the muesli bar.Easy to operation.
Characters:
1. Frequency control,flatting and cutting for one time
With With multiple level structure, pressed flat, uniform thickness
2. With multiple flat structure,pressed flat,uniform thickness
3. Automatic cutting ,Time saving, labor saving, economical and convenient

Smart Supply Snack Food Candy Bar Production Machine With CE ISO Passed

Smart Supply Snack Food Candy Bar Production Machine With CE ISO Passed

Machine samples:

Smart Supply Snack Food Candy Bar Production Machine With CE ISO Passed

Customer feedback:

Smart Supply Snack Food Candy Bar Production Machine With CE ISO Passed

Machine test video:

https://youtu.be/t2l1ZxbbTRk( high-thickness sample)
https://youtu.be/2eygOiiLbFQ (Dubai customer test peanut bar)
https://youtu.be/kYDVqXpltug (bird treat bar cutting)
https://youtu.be/NSVhOFzOYZc (cereal bar cutting with auto-sorting and cooling tunnel)
https://youtu.be/l9ob8_r6EgE (Test for American customer)

Any interest, please contact us freely!
