Specifications
Brand Name :
Smart
Model Number :
SR series
Certification :
ISO CE
Place of Origin :
China
MOQ :
1 set
Price :
negotiable
Payment Terms :
L/C, T/T
Supply Ability :
100 sets/month
Delivery Time :
35-40 working days
Packaging Details :
Standard export package
Product Name :
Injection Molding Pet Treat Machine
Motor :
WEG OR SIEMENS
Electric Parts :
ABB or Schneider
Application :
Pet
Voltage :
220V/380V or as customer assigned
Condition :
New
Description

Injection Molding Pet Treat Machine

Instruction of the injection molding machine

Dental chew bone injection molding machine is the essential equipment to make dental chews/pet treats/dog snacks.
Smart as the professional manufacturer of pet food machines, also supply cold extrusion pet treat machine, auto meat strip forming machine,meat strip machine, pet treat machine, pet treats molding machine, dog treat molding machine, pet treat molding machine, dog chewing bone molding machine.
Pet treats injected molding machine is special machinery for producing pet snacks. with such machine, various shapes can be made, such as hedgehog, crocodile, dog, bone, pork ears, barrel, etc.
The shapes of pet treats are very lovely and it is a ideal encouragement to dogs and cats while they learn a new action or do well in some exercises and games. also, we can provide different recipes to meet various market demands.

a. Raw Materials: adopts corn flour, fish meal and so on as raw materials.
b. Products: different shapes are made by adjusting the dies from extruder.
c. Flow chart:
Mixing system---Extrusion system---Injection system---Molding system---Packing system
d. Voltage in China: Three phases: 380V/50Hz, Single phase: 220V/50Hz, we can make it according to customers' Local voltage according to different countries
e. Machines Materials: All the Pet treats molding machine are made by stainless steel, this line is with reasonable design and with high automation

Parameter:

Item Name of item Unit DM-268
Injection Unit Screw Diameter mm 55
Screw L/D Ratio Ratio 20
Injection Volume (Theoretical) cm 601
Injection Weight (PS) g 548
Injection Pressure Mpa 185.1
Injection Rate into Air g/s 223.7/276.1
Injection Stroke mm 256
Injection Speed Mm/s 95/116
Screw Speed rpm 201/246
Clamping Unit Clamping Force KN 2600
Clamping Stroke mm 550
Space Between Tie-bars mm*mm 580 * 580
Max. Mould Height mm 600
Min. Mould Height mm 250
Ejector Stroke mm 160
Hydraulic Ejection KN 68
Ejector Rob Quantity pcs 9
Others Max. Pump Pressure Mpa 17.5
Pump Motor Power kw 22/30
Heater Power kw 15.9
Hopper Volume L 50
Oil Pump Volume L 550
Machine Weight t 8.5
Mould Positioning Ring Diam mm 160
Sphere Radius mm SR10
Machine Dimension m *m * m 5.82 *2 * 2


Samples By Our Pet treats molding machine
Our Pet treats molding machine can make pet chews with various shapes and tastes through changing the dies and formulas
We have full formula of foods and will guide you to use different materials to produce variety quality food.
Strong Packing for Pet treats molding machine
Packed by standard wooden case or wrapped by plastic film then shipped by container for Pet treats molding machine .

Machine and sample pictures:

CE Certificated Dog Treats Automatic Injection Moulding Machine High Effency
CE Certificated Dog Treats Automatic Injection Moulding Machine High Effency
CE Certificated Dog Treats Automatic Injection Moulding Machine High Effency


Video:

Smart plant:



Working video:


More details and price ,please contact us FREELY
