40km 10G SFP+ AOC DAC Cable DWDM Fiber Optical Transceiver LC Duplex DOM C17-C61
40km 10G SFP+ AOC DAC Cable DWDM Fiber Optical Transceiver LC Duplex DOM C17-C61
Specifications
Brand Name :
CFOFC
Model Number :
CFOFC- 10G SFP+ 40km
Certification :
ISO9001/ REACH / ROHS
Place of Origin :
Shenzhen, China
MOQ :
10Pcs
Price :
Negotiable
Payment Terms :
L/C, T/T,Paypal, Western Union
Supply Ability :
30,00000 pcs per month
Delivery Time :
5-8 work days
Packaging Details :
Individual Pack , plus outer cartons
Product name :
10G SFP+ 40km DWDM Optical Transceiver
Application :
Telecommunications,FTTH FTTB FTTX Network,Network
Connector type :
LC
Data Rate :
10G/s
Wavelength :
c17-c61
Transmission Distance :
40km
Description

10G SFP+ 40km DWDM Fiber Optical Transceiver LC duplex DOM C17~C61

Description of Optical Module

DWDM SFP+ transceivers are designed to transmit and receive optical data over single mode optical fiber. Digital diagnostic functions are available via an I2C.This module is designed for single mode fiber and operates at a nominal wavelength of ITU Grid,C Band DWDM wavelength. It is with the SFP+ 20-pin connector to allow hot plug capability. The transmitter section uses a DWDM EML laser and is a class 1 laser compliant according to International Safety Standard IEC-60825.The receiver section uses a PIN detector and a limiting post-amplifier IC.

Specification of Optical Module

Data Rate

 distance wavelength LD PD Connector DDM
10G 40km CWDM(1270-1330nm) DFB PIN LC Y
10G 80km CWDM(1470-1610nm) EML APD LC Y

Features of Optical Module

Optical interface compliant to IEEE 802.3ae

Electrical interface compliant to SFF-8431

Specifications compliant with SFF 8472

Hot Pluggable

Low power consumption

All-metal housing for superior EMI performance

Single +3.3v power supply

Support Digital Diagnostic Monitoring Interface

Case operating temperature range: 0°C to 70°C

RoHS 6 compliant and lead free

Satisfy Class I safty requrement

Application of Optical Module

10G Ethernet with FEC

10Gbps SONET/SDH ITU-T G.959.1 P1L1-2D2

10Gbps SONET/SDH ITU-T G.709

10G BASE-ZR/ZW

SFP footprint 80km 10G Fiber Channel
