Waterproof 16 Core Fiber Optic Distribution Box IP68 FTTH Pre Loaded
Waterproof 16 Core Fiber Optic Distribution Box IP68 FTTH Pre Loaded
Specifications
Brand Name :
CFOFC
Model Number :
Fiber Optic Distribution box
Certification :
Rohs ISO 9001
Place of Origin :
Shenzhen
MOQ :
1000
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
10000pcs per week
Delivery Time :
5-8 work days
Application :
FTTH FTTB FTTX Network
Color :
White
Product name :
Fiber Optic Distribution box
material :
ABS+PC
Type :
Outdoor/Indoor
connector :
SC LC
Description

Pre Loaded Waterproof 16 Core IP68 FTTH FTTH Fiber Distribucion Box

Description OF Fiber Distribucion Box

It is used as a termination point for the feeder cable to connect with drop cable in FTTx communication network system. The fiber splicing, splitting, distribution can be done in this box, and meanwhile, it provides solid protection and management for the FTTx network building.

Specification OF Fiber Distribucion Box

Name FTTA Nap Fiber Distribution Box with Huawei Waterproof Connectors
Size (Pic 1) A*B*C(mm) 208X241X117mm
Installation Size(Pic 2) (mm) D*E*F: 179*212*126 G*H: 21*52
Capacity 16 Core, Huawei Mini SC IP rated Waterproof connectors
In-put Port Cable diameter:12mm
Output Port Suitable for HUAWEI Type Waterproof Connector
Color for Port IN: red; NIX: green
Material PC+ABS
Weight 1.3Kgs
Protection Grade IP68

Features OF Fiber Distribucion Box

Total enclosed structure.

Material: PC+ABS, wet-proof, water-proof, dust-proof, anti-aging, protection level up to IP65.

Clamping for feeder cable and drop cable, fiber splicing, fixation, storage,

distribution...etc all in one.

Cable, pigtails, and patch cords are running through their own paths without disturbing each other, micro type PLC splitter

installation, easy maintenance.

Distribution panel can be flipped up, feeder cable can be placed by expression port, easy for maintenance and installation.

The box can be installed by the way of wall-mounted or poled-mounted, suitable for both indoor and outdoor use.

Application OF Fiber Distribucion Box

Wall-mounted installation

Drill 3 holes into the wall based on the installation size, place the expansion bolt Φ7.5*40, place the box to match up the holes

and use the bolt to fasten.

Pole-mounted installation

Fix 1 set of the pole ring to the telecom pole

Waterproof 16 Core Fiber Optic Distribution Box IP68 FTTH Pre LoadedWaterproof 16 Core Fiber Optic Distribution Box IP68 FTTH Pre LoadedWaterproof 16 Core Fiber Optic Distribution Box IP68 FTTH Pre LoadedWaterproof 16 Core Fiber Optic Distribution Box IP68 FTTH Pre Loaded

The reason why Choose us

1. Our shipping time is strictly controlled

2. We can provide customized service, according to the order requirements, can be equipped with a salesman and an engineer

3. Our company has rich export experience and is familiar with the customs policies of various countries

4. Large product inventory with massive production line

5. China's professional gas detection leader

FAQ

1. Are you factory direct?

as a professional fiber patch cord manufacturer, specialized in Fiber Optic Patch Cord,MPO, Fiber Optic PLC Splitter. Our products are mainly exported to Europe, South America, and some other countries and areas.

2. What is your main products?

Outdoor fiber optic cables indoor fiber optic cables FTTH Drop cables ADSS

Indoor armored patch cords fiber cable Optical patch cords Sc LC FC ST MTP MPO optical patch cord

3. Product quality guarantee period?

20 years Guarantee for fiber optic cable

4. Do you have certificate for raw material?

We build long-term relationship cooperation with qualified ISO9001 ROHS raw material suppliers
