Plate Bonding Steel Epoxy Adhesive For Warehouse Columns Strengthening

XQ-GZ Grouting Adhesive

Plate Bonding Steel Epoxy Adhesive For Warehouse Columns Strengthening is a new two components structure grouting adhesive, which can bonded with many kinds of base materials (cements, stone, and bricks, etc.) , metal and steel plate, its features fast curing, high strength, strong anchoring, acid and alkaline resistance, ageing resistance.

Range of Application

Reinforcement for structural heavy steel plate, wet wrapping steel, bonding steel by grouting after welded

Grouting and reparing for Assembling gap of Prefabricated unit and empty drum in the cover of all kinds of base materials (concrete, stone, brick, rock)

Grouting and fixing for machinery and equipment, hanging objects, prestressing tendons and bonding of metal bar

Bonding of other section units.

Grouting and repairing for concrete interior defects (crack, honeycomb, holes),and other section units.

Steel bonding reinforcement for flexual section units of concrete, new and old buildings

Features

1. Liquid easy to repair the small cracks on concrete

2. Two components, fast curing under room temperature

3. Quick to load with building structure, high boning strength, good pressure and pulling resistance, no shrink after curing.

4. Can be proceeded under wide temperature range, easy and good performance

5. Good resistance with Acid and alkaline, ageing,oil and water. Etc.

6. Low viscosity, good fluidity and high penetrability

7. Mostly suitable for all building base materials.

Product performance

Available handling time: (25℃): ≥30min

Shelf time: 24 months

Mixed Viscosity: 10-12 Pa.s

Hardened density: 1.50±0.10g/cm³

Mixing ratio: 3:1

Part A (main): White cream

Part B (hardener): Black cream

Processing Flow

Unloading → Base layer treatment → Pre-bonding → Mixing adhesive → Glue → bonding → fixedly adding pressure → Hardening and maintenance → Unfix the support and inspection→ anti-corrosion treatment → Panting

Packaging and Logistics

1. Two components packed separately, the mixing ratio is 2:1

2. Shall be stored in cool (under 25℃), dry and ventilated place, no exceed 1 year.

3. This product is non dangerous goods, can be shipped as normal chemical materials.

Attention

Mixed as per stipulated ratio, do not use too much each time,

Nontoxic, If accidentally touched by skin, clean with acetone and wash by water.

Must wear gloves, masks and other safety products.
