1.4mm Thickness CFRP Sheets Resin Impregnated For Bridge Tunnel Reinforcement
1.4mm Thickness CFRP Sheets Resin Impregnated For Bridge Tunnel Reinforcement
Specifications
Brand Name :
XINCHOR
Model Number :
XQ-P12
Place of Origin :
China
MOQ :
100 meters
Delivery Time :
30 days
Packaging Details :
100 meters per roll in carton
materials :
carbon fibre CFRP sheet
thickness :
1.4mm
tensile strength :
2400Mpa
Elastic Modulus :
170000Mpa
Elongation :
1.6
Price :
Negotiable
Description

carbon fibre CFRP sheet

XQ Carbon Fiber CFRP Sheet

Carbon fiber reinforced unidirectional sheet, carbon fibre CFRP sheet formed as putting the carbon fiber impregnated with resin, then hardened in mould and pultrusion. Adopted with high quality carbon fiber material with good basic resins, carbon fiber sheets feature good performance as high tensile strength, corrosion resistance, shock resistance, impact resistance.

Range of Application

Bending, and Shearing reinforcement for Concrete beams

Reinforcement for Concrete floors, bridge, concrete and brick walls.

Reinforcement for shear wall, bridge piers and piles

Reinforcement for chimneys, tunnels, pools and concrete pipe

Features

1, high tensile strength, corrosion resistance, shock resistance, good impact resistance;

2, light weight, good flexibility;

3, easy for handling and good quality assurance

4, good durability and corrosion resistance.

Product performance

1. Basic parameters

1) Specification: 1.0mm, 1.2mm, 1.4mm, 2.0mm thickness

2) Strength class: high strength grade I, high strength grade II;

3) Length: 50m, 100 m

4) Width: 50mm, 100mm, rolled as ring and binded by belt.

5) Specific gravity: 1.6

2. Main Performance

Testing project Index
High Strength Grade I
Tensile strength ≥2400 MPa
Tensile modulus of elasticity ≥1.7×105 MPa
Elongation ≥1.6 %
Layer cutting strength ≥50 MPa

Cohesive pulling strength with base materials

To concrete and brick materials, ≥2.5MPa based on cohesive damage

To Steel, ≥3.5 no bonding damage
Fabric content in volume ≥65 %

Remarks: all technical data are average values.


Processing Flow

Preparation → Concrete surface treatment → Mix and paint the base resin material → Leveling → Mix and paint the impregnated resin → Pasting the carbon fiber sheet → Surface protection.

Attention

1, on-site workers should take appropriate protection measures and take care of fire and keep good ventilation.

2, When open the roll, the sheet may occur to bounce up, pay kind attention.

3, The sheet is conductive, take care of the electrical appliances nearby.
