Epoxy Low Viscosity Carbon Fiber Adhesive With High Bonding Strength

Xinchor CFRP Carbon Fiber Adhesive is Low viscosity, strong penetration ability, used for smearing of the underlayer of reinforced members' surface, the role is penetration bonding reinforcement to the broken concrete after chiseling off; of the surface of members was intact, smearing was not needed.

Two components in separate plastic barrel, 30kgs/set, Mix ratio (weight) A:B=2:1

Shall be stored in cool (between 10-35℃), dry and ventilated place, not exceed 1 year.

Toxic free, non dangerous, can be shipped as normal chemical materials.

Basic parameters

1) Appearence

Part A (main): transparent liquid

Part B (hardener): Brown transparent liquid

2) Mixed Viscosity: 4000-6000 Pa.s

3) Hardened density: 1.10±0.10g/cm³

4) Available handling time: (25℃): ≥30min

5) Shelf time: 24 months

Usage

Adhesive for bonding external reinforcement to concrete, masonry, steel, wood, stone, etc.

Structural bonding of composite laminates (Sika® CarboDur® CFRP) to concrete.

Structural bonding of steel plates to concrete.

Suitable for use in vertical and overhead configurations.

As a binder for epoxy mortar repairs.

Transportation and Storage

• The carbon fiber adhesive should store in a cool and dry place,storage period is 12 months. If storage period exceed 12 months, the product should be tested, if the physical and mechanical properties meet the standard requirements,you can still continue to use it.

• This product is non-toxic, belong to non-dangerous goods, transport as a goods, transport as a general chemical building materials.

Attention Points

• Mix proper quantity, use up in the applicable period.

• If there is any left, the lids of A B should be covered. Do not expose it in the air.

• Construction workers should take certain protective measures.

• The construction environment should be kept ventilated during construction.

• Avoid direct sunlight and high temperature.
