12.7 X 12.7mm Size Stainless Steel Welded Mesh 1.6mm Wire Industrial Grade
12.7 X 12.7mm Size Stainless Steel Welded Mesh 1.6mm Wire Industrial Grade
12.7 X 12.7mm Size Stainless Steel Welded Mesh 1.6mm Wire Industrial Grade
12.7 X 12.7mm Size Stainless Steel Welded Mesh 1.6mm Wire Industrial Grade
Specifications
Brand Name :
X MESH
Model Number :
X MESH-Stainless Steel Welded Mesh 010
Certification :
ISO9001:2015
Place of Origin :
Hebei P.R. China.
MOQ :
1000m2
Price :
USD1.85-2.35/m2
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
85000m2/week
Delivery Time :
5-7days
Packaging Details :
Wrapped with plastic film and pallet packing
Product Name :
Stainless Steel Welded Panels
Wire Diameter :
1.6mm
Mesh Size :
12.7 x 12.7mm
Grade :
304
Type :
Rolls
Length :
30m
Feature :
Long term life cycle and performance
Application :
For Industrial Plant
Color :
Silver
Packing :
Bundle/Wooden Case/Pallet
Description

12.7 x 12.7mm Mesh Size 1.6mm Wire Industrial Grade Stainless Steel Welded Mesh

Stainless Steel Welded Mesh Introduction:

Stainless steel welded mesh is manufactured by the longitudinal and transverse wires being resistance welded together.

Qijie Company stock stainless mesh in both 304 and 316 grades. All our welded mesh rolls come in 30 metre lengths but we're happy to cut lengths to your exact requirements. We won't force you to purchase more than you need.

Product Name

Stainless Steel Welded Mesh

Wire Diameter

1.6mm

Mesh Size

12.7 x 12.7mm

Grade

304

Type

Rolls

Length

30m

Feature

Long term life cycle and performance

Application

For Industrial Plant

Color

Silver

Packing

Bundle/Wooden Case/Pallet

Stainless Steel Welded Mesh Specification:

PARENT CODE

MESH MM

WIRE DIAMETER MM

SSWM 06.35 0.63

6.35 x 6.35

0.63

SSWM 06.35 0.8

6.35 x 6.35

0.8

SSWM 09.50 0.8

9.50 x 9.50

0.8

SSWM 09.50 1.0

9.50 x 9.50

1

SSWM 11.00 0.8

11.0 x 11.0

0.8

SSWM 12.7 1.0

12.7 x 12.7

1

SSWM 12.7 1.2

12.7 x 12.7

1.2

SSWM 12.7 1.6

12.7 x 12.7

1.6

SSWM 12.80 1.2

12.7 x 25.4

1.2

SSWM 19.05 1.6

19.05 x 19.05

1.6

SSWM 19.05 2.0

19.05 x 19.05

2

SSWM 25.4 1.0

25.4 x 25.4

1

SSWM 25.4 1.2

25.4 x 25.4

1.2

SSWM 25.4 1.6

25.4 x 25.4

1.6

SSWM 25.4 2.0

25.4 x 25.4

2

SSWM 50.8 2.0

50.8 x 50.8

2

Grade Length Width L/W Spacing C/W Spacing L/W Diam C/W Diam Weight (kg)
304 2.4m 1.2m 25mm 25mm 2.5mm 2.5mm 9.02
304 2.4m 1.2m 50mm 25mm 3.15mm 3.15mm 10.79
304 2.4m 1.2m 50mm 50mm 3.15mm 3.15mm 7.27
304 2.4m 1.2m 50mm 50mm 4mm 4mm 11.72
304 2.4m 1.2m 50mm 50mm 5mm 5mm 12.4
304 2.4m 1.2m 50mm 75mm 5mm 5mm 15.35
316 2.4m 1.2m 25mm 25mm 2.5mm 2.5mm 9.02
316 2.4m 1.2m 50mm 50mm 3.15mm 3.15mm 7.27
316 2.4m 1.2m 50mm 50mm 4mm 4mm 11.72
316 2.4m 1.2m 50mm 50mm 5mm 5mm 12.4

Stainless Steel Welded Mesh Feature:

* Smooth mesh surface and bright luster
* Well-proportioned meshes
* Strong welded points
* High solid structure
* Corrosion-resisting
* Oxidation-resisting

Stainless Steel Welded Mesh Application:

Stainless steel welded wire mesh is mainly used for mining, petroleum, chemical, food, medicine, machinery manufacturing and other industries of machinery and equipment protection, highway guardrail, sports venues fence, the road green belt protection. Also be used for construction, roads, bridges for reinforcement.

12.7 X 12.7mm Size Stainless Steel Welded Mesh 1.6mm Wire Industrial Grade

12.7 X 12.7mm Size Stainless Steel Welded Mesh 1.6mm Wire Industrial Grade

12.7 X 12.7mm Size Stainless Steel Welded Mesh 1.6mm Wire Industrial Grade

12.7 X 12.7mm Size Stainless Steel Welded Mesh 1.6mm Wire Industrial Grade

12.7 X 12.7mm Size Stainless Steel Welded Mesh 1.6mm Wire Industrial Grade
