Green Powder Coated Palisade Fence Panels Pale Thickness 3mm For Thermal Power Plant
Green Powder Coated Palisade Fence Panels Pale Thickness 3mm For Thermal Power Plant
Green Powder Coated Palisade Fence Panels Pale Thickness 3mm For Thermal Power Plant
Green Powder Coated Palisade Fence Panels Pale Thickness 3mm For Thermal Power Plant
Specifications
Brand Name :
X MESH
Model Number :
X MESH-Palisade Fence05
Certification :
ISO9001:2015
Place of Origin :
Hebei P.R. China.
MOQ :
50sets
Price :
USD25.00-75.00/Set
Payment Terms :
T/T, Western Union, L/C, MoneyGram
Supply Ability :
5000sets/week
Delivery Time :
5-8days
Packaging Details :
Wrapped with plastic film and pallet packing
Name :
wrought iron fences
Material :
Galvanized Steel
Height :
1.8m, 2.2m, 2.4m, 3.0m
Width :
2.75m
Pale Thickness :
2/2.5/3mm
Pale Quantity :
17
2 Pieces of Rail angle :
50X50X5mm
Application :
for thermal power plant
Feature :
Crossion Resistance & Durable
Packing :
Pallet/Wooden Case
Description

Green Powder Coated Pale thickness 3mm palisade fence panels forthermal power plant

palisade fence panels Description:

Palisade Fence is one of security fencing series. It is popular in Europe, Africa, Australia, PNG, etc. Iit is widely used because of people's environment pursuit, publicity of personal cleanliness and pursuit of foreign style. Palisade fencing with beautiful structure and various styles are popular and widely used.

Name

palisade fence panels

Material

Galvanized Steel

Height

1.8m, 2.2m, 2.4m, 3.0m

Width

2.75m

Pale Thickness

2/2.5/3mm

Pale Quantity

17

2 Pieces of Rail angle

50X50X5mm

Application

for thermal power plant

Feature

Crossion Resistance & Durable

Packing

Pallet/Wooden Case

palisade fence panels Specification:

Specification of W-Section Type palisade fence

Panel Size

W-Section Pale: 70 mm

Horizontal Rail

Post

Height

Width

Pale thickness

Qty: Pale

Angle Steel

Square Post

I Post

1.8 m

2.75 m

2/2.5/3 mm

17 pcs

40 × 40 × 4 mm, 50× 50 × 6 mm

60 × 60 mm, 80 × 80 mm, 100 × 100 mm

100 × 55 mm

2.1 m

2.75 m

2/2.5/3 mm

17 pcs

2.4 m

2.75 m

2/2.5/3 mm

17 pcs

3.0 m

2.75 m

2/2.5/3/3.5 mm

17 pcs

W-section Pale: 62 mm

1.8 m

2.75 m

1.5/2/2.5 mm

17 pcs

40 × 40 × 4 mm, 50× 50 × 6 mm

60 × 60 mm, 80 × 80 mm, 100 × 100 mm

100 × 55 mm

2.1 m

2.75 m

1.5/2/2.5 mm

17 pcs

2.4 m

2.75 m

1.5/2/2.5 mm

17 pcs

3.0 m

2.75 m

1.5/2/2.5 mm

17 pcs

D-Section Pale: 65 mm

Panel Size

D-Section Pale: 65 mm

Horizontal Rail

Post

Height

Width

Pale thickness

Qty: Pale

Angle Steel

Square Post

I Post

1.8 m

2.75 m

1.5/2/2.5/3 mm

17 pcs

40 × 40 × 4 mm, 50× 50 × 5 mm

60 × 60 mm, 80 × 80 mm, 100 × 100 mm

100 × 55 mm

2.1 m

2.75 m

1.5/2/2.5/3 mm

17 pcs

2.4 m

2.75 m

1.5/2/2.5/3 mm

17 pcs

3.0 m

2.75 m

1.5/2/2.5/3 mm

17 pcs

Pales-"W" section

Most useful vetical type of pales for d section galvanized palisade fence, which is always the customers' first choice for pales .

width

thickness

surface treatment

head

65 mm
68 mm
70 mm

2.0 mm
2.5 mm
3.0 mm

powder painted
hot dipped galvanized only 450 grams per square meter

triple pointed top
single pointed top
round top
round and notch top

Pales-"D" section

Compared with "W" profile pales, "D" profile is more economical.

Post- H Type

As a connection pipe between the fence panel, H type is the most useful way.

size

thickness

surface treatment

head

100x55mm 100x68mm
120x74mm

3.5 mm
4.0 mm
4.5 mm
5.0 mm

powder painted
hot dipped galvanized only 450 grams per square meter

cut sharp

Rail- Angle Iron

It is the connection between pales and IPE post, which make the fence as a whole panel.

Fittings- Fish plate, Bolts & Nuts(M8x40,M12x30)

Fish plate is used as the connection between the H post and the angle rail.

palisade fence panels Feature:

  • Palisade fence: One pointed, triple pointed, rounded, rounded & notched and square top. Palisade gate: Singular leaf or double leaf, swing or sliding gate, cantilever gate. Steel palisade fence: Made of low carbon steel, mild steel, hot or cold rolled steel. Galvanized palisade fence: Palisade fence or palisade gate can be finished with hot-dipped or electric galvanized. Palisade pales: The pales can be W section, D section and angle section. Palisade post: The palisade posts have square type and RSJ beam type. Palisade rail: Angle type with slots to fix. Palisade fittings: Connecting parts include fishplates, post clamps, bolts and nuts.

palisade fence panels Application:

Palisade is the ideal solution for any business, school or public space in need of a strong, durable perimeter.

Powder coating in an array of colours means that this product can be matched to corporate and brand identities or

customised to assimilate with surrounding environments.

Whye Choose us:

1.Our factory specialize in design,manufacturing galvanized steel or aluminium fence, railing etc

2. Experienced sales team, engineer team, designer team and skillful workers.

3. Advanced equipment, mature production technology, strong production capability.

3. Our products surface is made of branded powder, with strong lacquer coating and strong adhsion Strict quality control system, environment friendly and anti-corrosion.

4. Perfect after-sales service,15-year maintenance.

5. Assembled product is convenient for transportation
