A4 copy paper packaging machine, paper wrapping machine
A4 copy paper packaging machine, paper wrapping machine
A4 copy paper packaging machine, paper wrapping machine
A4 copy paper packaging machine, paper wrapping machine
A4 copy paper packaging machine, paper wrapping machine
A4 copy paper packaging machine, paper wrapping machine
Specifications
Brand Name :
Chancer
Model Number :
BTCP-297A
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Price :
USD46500 per set
Payment Terms :
T/T
Supply Ability :
80sets per year
Delivery Time :
30 days
Packaging Details :
seaworthy package
A4 copy paper size (standard) :
297×210×（48-60）mm
Power :
5Kw
Compressed air :
0.6-0.7Mpa
Description

A4 copy paper packaging machine, paper wrapping machine

USE:

Main structure is driven by a series of cams and connecting rods and working accessories to finish the packaging. High stability, low noise.

Applying frequency conversion with multi-function digital non-ploy speed, adopting Siemens PLC program controlled. Touch screen realizing human-machine interface.

For roll paper package, It has automatic clutch controlled device to make the roll paper have the function of automatic elevation and subsidence photocell sensor, cutting accuracy of color film.

If package material is PE laminated paper, machine is connecting gluer and the spray adjustable. If package material is printed film photocell sensor will be provided so as to reduce the packing cost and also improve cutting accuracy of color film, wrapping effect and sealing performance.

Main technical parameter:

Model BTCP-297A
Productive capacity 13-15(packs/min)
A4 copy paper size (standard)

297×210×(48-60)mm

(based on 500 pieces of A4 copying paper)
Voltage 380V 50-60Hz
Power 5Kw
Compressed air 0.6-0.7Mpa
Overall dimensions 420×1300×170mm(L×W×H)with safety cover
Weight 1700Kg
Package material Printed Single paper

Contacts:

A4 copy paper packaging machine, paper wrapping machine

Machine picture:

A4 copy paper packaging machine, paper wrapping machine

Sample:

A4 copy paper packaging machine, paper wrapping machine
