CPCD50 Forklift Equipment , 5 Ton Electric Forklift Easy Maintenance
CPCD50 Forklift Equipment , 5 Ton Electric Forklift Easy Maintenance
Specifications
Brand Name :
changlin
Model Number :
CPCD50
Place of Origin :
CHINA
MOQ :
1
Price :
USD5000-USD100000
Payment Terms :
L/C, T/T
Supply Ability :
30units/per month
Delivery Time :
5-8work days
Model :
CPCD50
Power type :
Diesel
Rated load capacity (kg) :
5000
Load centre (mm) :
500
Rated lift height (mm) :
3000
Free lift height (mm) :
160
Fork size (L×W×T) (mm) :
1070*150*50
Mast tilt angle (F/R, α°/β°) :
6°/12°
Fork overhang (wheel center to fork face) (mm) :
555
Ground clearance (Bottom of Mast) (mm) :
150
Length to face of fork (without fork) (mm) :
3175
Overall width (wheel) (mm) :
1490
Overhead guard height (mm) :
2310
Wheelbase (mm) 2000 :
2000
Turning radius (outside) (mm) :
2780
Travel speed (loaden/unloaden) (km/h) :
23.5/25
Lifting speed (loaden/unloaden) (mm/s) :
400/440
Lowering speed (loaden/unloaden) (mm/s) :
460/440
Max. gradeability (loaden/unloaden) (%) :
20/23
Total weight (kg) :
6750
Engine model :
LR4B3
Rated power :
57kw@2200rpm
Rated torque :
285N.m@1400rpm
Name :
5 Ton Electric Forklift
Description

DIESEL FORKLIFTCPCD50

  • The diesel forklift offers enhanced operational visibility through an increased inside width of the inner mast and the distance between inner mast rails. The forward visibility is greatly improved by lowering the instrument panel, and the rearward visibility is enhanced by improving the design of counterweight;
  • Heavy-duty chassis or flexible type chassis is optional;
  • The enlarged opening angle of hood and addition of left and right hood side plates make the maintenance of the forklift easier and quicker;
  • The engine of diesel forklift provides high power output, low emission and good cold starting performance, the energy consumption is reduced by 10%;
  • The new generation of integrated electric box is adopted in the diesel forklift for easy maintenance and repairing, it has reasonable layout and good water-proof performance;
  • Large size tapered roller bearing (TRB) is used on the steering axle king pin, larger steering cylinder and bumper block assemblies are employed for longer service life of bearing and improved reliability of steering axle;
  • The overhead guard is fabricated using special-shaped steel tube, ensuring reinforced strength and improved sealing of cab;
  • Small diameter steering wheel, electro-hydraulic system and double-handle combination switch are used for increased operator's comfort;
