2200L Rotor Stator Homogenizer Emulsifier Mixer With High Shear
2200L Rotor Stator Homogenizer Emulsifier Mixer With High Shear
2200L Rotor Stator Homogenizer Emulsifier Mixer With High Shear
2200L Rotor Stator Homogenizer Emulsifier Mixer With High Shear
Specifications
Place of Origin :
Shanghai, China
Brand Name :
Chasing
Certification :
CE
Packaging Details :
Standard wooden case
Supply Ability :
50 Set/Sets per Month
Price :
Negotiable
Model Number :
ZGF
MOQ :
1 SET
Payment Terms :
T/T, L/C
Mixer Type :
Homogenizer
Barrel Volume (L) :
2000
Max. Loading Volume (L) :
2200 L
Range of Spindle Speed(r.p.m) :
1 - 3600 r.p.m
Weight (KG) :
65 KG
Material :
SUS316L
Application :
Viscous Fluid, Medicine Processing, Chemicals Processing, Food Processing
Voltage :
3phases 200V/380V/415V/480V/600V
Dimension(L*W*H) :
1000*400*1000mm
Power (kW) :
15 kW
Description

Shanghai Chasing injection Rotor Stator Homogenizer with high shear

SGF hydraulic rising high shear of Technical parameter

model Power(kw/hp)power lift height emulsifying head diameter rotating speed mixing volume
SGF-4T 4 1000 140 1500 200-500
SGF-7.5T 7.5 1000 150 1500 400-900
SGF-11T 11 1000 160 1500 500-1500
SGF-15T 15 1000 180 1500 800-2200
SGF-18.5G 18.5 1000 200 1500 1000-2500
SGF-22T 22 1000 240 1500 1200-3000

2200L Rotor Stator Homogenizer Emulsifier Mixer With High Shear

2200L Rotor Stator Homogenizer Emulsifier Mixer With High Shear

High shear homogenizing emulsifier

Principle:The materials willbe processed in the narrow space between stator and rotor by high tangential speed and strong energy of motion respectively produced by fast-turning rotor and high frequency mechanical effect. By the operation of intensively shearing, centrifugally extruding ,impacting and breaking, liquid layer attrition and even turbulence,the materials of solid phase, liquid phase and gas phase that cannot dissolve will be refined ,dispersed and emulsifierd.

2200L Rotor Stator Homogenizer Emulsifier Mixer With High Shear
