Stainless Steel 316L 10000L Inline Homogenizer For Cosmetic
Stainless Steel 316L 10000L Inline Homogenizer For Cosmetic
Stainless Steel 316L 10000L Inline Homogenizer For Cosmetic
Stainless Steel 316L 10000L Inline Homogenizer For Cosmetic
Stainless Steel 316L 10000L Inline Homogenizer For Cosmetic
Stainless Steel 316L 10000L Inline Homogenizer For Cosmetic
Specifications
Brand Name :
CHASING
Model Number :
ZGF
Certification :
CE,PED,UL,CSA
Place of Origin :
China
MOQ :
1
Payment Terms :
L/C, T/T, , D/P
Supply Ability :
35sets/month
Delivery Time :
45 days
Packaging Details :
Export Standard Wooden Case
Voltage :
3phases 200V/380V/415V/480V/600V
Mixer type :
Homogenizer rotor and stator
Application :
Liquid with Suspended Solids,Chemicals Processing,Viscous Fluid,Medicine Processing,Food Processing
Max. loading capacity :
10000L
Dimension(l*w*h) :
Customized
Material :
stainless steel 316L &304
After-sales service provided :
Engineers available to service machinery overseas,Online support,Video technical support
Warranty :
Over 5 years
Description

high pressure homogenizer

1. Select the international famous-brand motor for us, with lower noise and more stable operation to ensure the high quality of the whole machines;
2. Free of pollution to materials, it is ideal choice for high quality and lustration such as medication, foodstuff, making-ups;
3. Reasonable design,convenient for cleaning, in accordance with GMP sanitary requirements;
4. Mechanical seal can be chosen: single end face, double end face;
5. Suitable for the atmosphere, obtuation, vacuum and pressure operating modes;
6. Application temperature≤ 160oC
7. The high-quality scattering,emulsification,homogeneity,dissolving and reaction etc, Process can be full realized, which solve the problems of following special operating cases; the impossible process distribution, required multiemulsified equipment, initial feeding less but must meet vacuum and pressure requirments.

Main technique parameter

Model (ZGF) 601 602 603 604 605 606 607 608 609
Power(KW) 1.5 4 7.5 11 18.5 22 37 55 75
Rotate speed(rpm) 6000 3000 3000 3000 3000 3000 1500 1500 1500
High(mm) 510 600 700 800 920 930 1150 1250 1380
Cubage(L) 10~30 50~200 50~400 100~500 500~2000 800~2500 1500~3000 2500~5000 4000~10000

Remark:

The measured medium is water for the max.batch processing capacity in the table;

The batch processing capacity depends on viscosity and solids content of the materials;

Insert in from the top of the vessel,while amounting,it has the requirement for high verticality.

Stainless Steel 316L 10000L Inline Homogenizer For CosmeticStainless Steel 316L 10000L Inline Homogenizer For CosmeticStainless Steel 316L 10000L Inline Homogenizer For Cosmetic
