220V Chemical Fume Hood Lab Acid Fume Hood Wall Mounted with Horizontal Structure
220V Chemical Fume Hood Lab Acid Fume Hood Wall Mounted with Horizontal Structure
220V Chemical Fume Hood Lab Acid Fume Hood Wall Mounted with Horizontal Structure
220V Chemical Fume Hood Lab Acid Fume Hood Wall Mounted with Horizontal Structure
220V Chemical Fume Hood Lab Acid Fume Hood Wall Mounted with Horizontal Structure
220V Chemical Fume Hood Lab Acid Fume Hood Wall Mounted with Horizontal Structure
220V Chemical Fume Hood Lab Acid Fume Hood Wall Mounted with Horizontal Structure
220V Chemical Fume Hood Lab Acid Fume Hood Wall Mounted with Horizontal Structure
Specifications
Brand Name :
SUCLAB
Model Number :
HZJ011
Place of Origin :
CHINA
Certification :
ISO9001, ISO14001
MOQ :
1 STE
Price :
Negociation
Packaging Details :
Export Plywood Package
Delivery Time :
15 Days
Payment Terms :
T/T, D/A, L/C, D/P, MoneyGram
Supply Ability :
10000 Sets /Month
Warranty :
1 Year
Material :
Stainless Steel,Full Steel ,Pp , FRP
Size :
Standard
Control System :
Microcomputer
Noise :
≤60dB
Product Name :
Acid Fume Hood
Structure :
Horizontal
Voltage :
220V
Air Flow :
150m3/h
Light Source :
LED
Lighting Intensity :
≥1000Lux
Power :
500W
Safety Device :
Yes
Sash Window :
Manual
Service Life :
5 Years
Description

220V Chemical Fume Hood Lab Acid Fume Hood Wall Mounted with Horizontal Structure

Product Description:

Our Lab Acid Fume Hood is the perfect solution for laboratories and industrial facilities to protect personnel from hazardous airborne contaminants. Constructed of durable stainless steel, this hood is designed to operate at 220V and provide an airflow of 400m³/h. The noise level of the hood is also kept to a minimum of 60 dB, ensuring a comfortable working environment. It also features a bright LED lighting system so that users can easily work with chemicals and substances safely. Additionally, the Chemical Fume Hood is designed to provide optimum performance and the highest degree of user safety.

1.Hood body&base cabinet: 8-12mm porcelain white PP (polypropylene) sheets, welded into one piece, welded by the same color and homogeneous electrode.
2.Standard Work surface: 12mm porcelain white PP (polypropylene) sheets.
***Optional: Phenolic Resin/Epoxy Resin/Stainless Steel/Ceramic/Trespa/Granite/Marble. 3.Controller: Intelligent switch with digital display, multiple controls such as power on, fan, lighting, socket, sterilization, damper, etc. 4.Glass sash: Use explosion-proof 5mm tempered glass, PP material sash handle. It is designed by the weight balance method in the mechanical principle, and the left and right are connected by synchronous wheels. 5.Lighting: Equipped with LED 30W purification lamp, the luminosity is greater than 300LUX, 6.Fume hood liner and Baffle: Use 8mm porcelain white PP (polypropylene) plate. 7. Junction box: The junction box with circuit board and AC contactor makes wiring more convenient. Suitable for 110V-230V voltage. 8. Standard accessories: 1x bench-mounted single water tap 1x PP oval cupsink 4x Electrical Outlets 1x 250 or 315mmφ PP hood. 9.Optional accessories: Remote Controlled Fixture gas&water faucet Explosion-proof light Distillation Grid Kit Acid and flammable base cabinet Ductwork Exhaust blower
Model
PPFH-120
PPFH-150
PPFH-180
External Dimension
(W*D*H)(mm)
1200*850*2350
1500*850*2350
1800*850*2350
Internal Dimension
(W*D*H)(mm)
1000*680*700
1300*680*700
1600*680*700
Base Cabinet Dimension
(W*D*H)(mm)
1200*800*850
(Can remove)
1500*800*850
(Can remove)
1800*800*850
(Can remove)
Exhaust air volume
700-1300m³/h
900-1700m³/h
1300-2100m³/h
Air Velocity
0.3～0.8 m/s
Features:
  • Product Name: Chemical Fume Hood Lab Acid Fume Hood
  • Control System: Microcomputer
  • Noise: ≤60dB
  • Size: Customized
  • Lighting: LED
  • Color: White

Applications:

Lab Acid Fume Hood from SUCLAB, model HZJ011, are manufactured in China and certified by ISO9001 and ISO14001. The minimum order quantity is one set and the price is negotiable. The packaging details of Chemical Fume Hood is Export Plywood Package and the delivery time is within 15 days. Payment terms are T/T, D/A, L/C, D/P, and MoneyGram. The supply ability is 10000 Sets per month. The material of Chemical Fume Hood is stainless steel and the color is white. The power is 50W and the control system is microcomputer. The voltage is 220V.

Customization:

  • Brand Name: SUCLAB
  • Model Number: HZJ011
  • Place of Origin: CHINA
  • Certification: ISO9001, ISO14001
  • Minimum Order Quantity: 1 SET
  • Price: Negociation
  • Packaging Details: Export Plywood Package
  • Delivery Time: 15 Days
  • Payment Terms: T/T, D/A, L/C, D/P, MoneyGram
  • Supply Ability: 10000 Sets /Month
  • Color: White
  • Installation Type: Wall Mounted
  • Product Name: Chemical Fume Hood
  • Control System: Microcomputer
  • Size: Customized

Support and Services:

Technical Support and Service for Lab Acid Fume Hood

At ABC Company, we are committed to providing our customers with the highest quality of technical support and service for our chemical fume hoods. Our team of experienced professionals is available to answer any questions you may have about our products, their installation, and their maintenance.

We offer a range of services to ensure that your fume hoods are installed correctly and are operating safely and efficiently. Our team can provide you with on-site installation and training, remote troubleshooting, and support for any repairs or upgrades.

We also have a comprehensive online library of product manuals and documentation, as well as a live chat system with our technical support team. If you have any questions about our chemical fume hoods, please do not hesitate to contact us.

220V Chemical Fume Hood Lab Acid Fume Hood Wall Mounted with Horizontal Structure

Packing and Shipping:

Packaging and Shipping of Lab Acid Fume Hood

The chemical fume hood is packaged with a superior-quality material in order to protect it from any damage incurred during the shipping process. The packaging also includes a moisture barrier to prevent moisture from entering the system and causing damage. It is then secured with a metal band to ensure its safety during the shipping process. The chemical fume hood is then shipped to the destination via a reliable carrier, such as FedEx or UPS.
